In view of the contradiction between the need of the electromagnetic sled for real-time accurate position and speed information and the limitation or high cost of traditional position and speed measurement methods, a new measurement system based on vernier caliper structure was proposed and designed.The principle of high precision positioning and the corresponding position analysis method was expounded, and the position prediction algorithm and Kalman filter algorithm were designed to improve the accuracy and real-time performance.The hardware circuit and software program were designed to realize the function, and a synchronous belt guide rail experimental platform was built to verify the designed system.The test results show that the system can achieve millimeter-level positioning accuracy, and performs well in terms of real-time capability, accuracy and engineering application.The positioning and speed measurement system was applied to the electromagnetic levitation propulsion platform.

Modular multilevel converters exhibit significant capacitor voltage ripple under low-speed, high-torque operating conditions. Existing high-frequency injection suppression schemes increase device current stress and losses while introducing overmodulation risk, and their parameter optimization lacks full operational-condition adaptability.To resolve this issue, a high-frequency injection parameter adaptive optimization strategy considering multiple constraints was proposed.Based on system characteristics and a steady-state model, a variable-step gradient descent algorithm was employed offline to generate a minimum injection-amplitude base parameter reference table that satisfies both capacitor voltage ripple and modulation wave constraints.Subsequently, an online adaptive correction mechanism was designed.Injection parameters were dynamically adjusted in real-time according to acquired capacitor voltage ripple and modulation information, compensating for model deviations and operational variations, forming a coordinated architecture of offline global optimization and online local refinement.Simulation and experimental results show that the proposed strategy maintains the capacitor voltage ripple suppression effect while significantly reducing high-frequency circulating currents, demonstrating dynamic tracking capability for the optimal objective.

To address the challenges of intelligent diagnosis for open-circuit faults in power electronic inverters, such as the lack of actual fault samples and the issue of varying characteristic adaptability, a set of optimization methods was proposed from two key intelligent elements:data and algorithm, to support the practical applications of intelligent diagnosis for open-circuit faults in power electronic inverters.For the data element, a fault sample amplification method based on inverters′characteristics was proposed, which finds out the minimum number of practical samples required for model training.For the algorithm element, an attention-enhanced method and a frequency points adaptive training method for the diagnosis model were proposed, which significantly improve model training effectiveness and diagnosis accuracy under wide-frequency inverter operation.The effectiveness of the proposed optimization methods for the intelligent elements was validated by experiments.

For the common stator winding short circuit and rotor eccentricity faults in surface-mounted permanent magnet synchronous motors, a flexible printed circuit board with small footprint and capable of accommodating a large number of windings was used to fabricate the detection coil, which was then arranged in the stator slots to capture magnetic field information.For the stator winding short circuit fault, a winding short circuit detection method using dual orthogonal phase-locked loop to extract fault characteristic values was proposed.This method can effectively distinguish the short circuit resistance, short circuit winding number, and fault location, and was not affected by the motor′s speed fluctuations.For the rotor eccentricity fault, a differential bridge structure of the detection coil based on high-frequency injection was proposed for eccentricity detection, and ultimately, a 2% eccentricity detection can be achieved.For the composite fault, a fault discrimination scheme based on convolutional neural networks was introduced, and the performance of different learning methods was compared.The experimental results show that under the composite fault condition, a 98% correct rate of winding short circuit assessment is achieved, and the eccentricity detection error using AlexNet with a training data proportion of 60% is only 5%.

An adaptive active disturbance rejection control strategy integrating DRL(deep reinforcement learning)with enhanced PSO(particle swarm optimization)was presented, aiming to improve the speed and thrust control performance of PMSLMs(permanent magnet synchronous linear motors).A mathematical model of the motor was established to analyze its dynamic characteristics, followed by the design of a DRLPSO control framework.This framework leveraged reward mechanisms in reinforcement learning to interact with the environment, dynamically optimized ADRC(active disturbance rejection controller)parameters to accommodate varying operating conditions and external disturbances.The modified PSO algorithm incorporated partitioned inertia weights and cyclically utilized historical global optimal data to iteratively update control policies, refining neural network weights and thereby enhancing search efficiency and optimization accuracy.Experimental results show that the proposedDRLPSO-ADRCmethod achieves significantly higher tracking precision in position and velocity, along with improved system stability and resistance to thrust disturbances, compared to conventionalPSO-ADRCalgorithms.These findings validate the effectiveness of the innovative control strategy.

To achieve accurate and stable online identification of inductance parameters for PMSM(permanent magnet synchronous motor), an online inductance observation method based on virtual voltage vector excitation and current differential response was proposed, which required no additional test signal injection and was decoupled from rotor position, stator resistance, and permanent magnet flux linkage.By introducing the concept of a virtual voltage vector-oriented coordinate system, it was analytically derived and proven that the d-and q-axis inductances of a PMSM can be observed independently of the angular position in the conventional d-q synchronous reference frame.Building on this, the implementation procedure for extracting virtual voltage vectors and current differential information was discussed in detail, enabling non-intrusive inductance identification without any signal injection.The effectiveness and accuracy of the proposed method were validated by comparison with offline test procedures in IEEE standards.

To improve the design performance of long-range guided rockets, a multidisciplinary parametric model of long-range guided rockets was first established to achieve high-precision performance simulation of guided rockets.A sequence approximation optimization method based on an improved augmented radial basis function was proposed, which enhanced the generalization ability of the augmented radial basis function model through anisotropic techniques.Recursive evolution experimental design and fast cross-validation were used to improve the efficiency of approximation modeling, and an imprecise search strategy was applied for sequence sampling.The effectiveness of the proposed optimization method was verified through numerical examples.A sequence approximate optimization design of the long-range guided rocket was carried out, and the maximum range increase by 16.7% compared to before optimization while satisfying design constraints.

Combining software defined networking and SR(segment routing)can optimize network performance, but in large-scale dynamic networks, excessive link utilization at key nodes can lead to a surge in queue delays.To address this, a SROD-LC(segment routing optimization algorithm based on deep reinforcement learning and load centrality theory)was proposed.By quantifying the importance of network nodes using load centrality theory, key nodes are identified and their link load states are monitored;utilizing a multi-agent reinforcement learning framework, distributed deep reinforcement learning agents are deployed at key nodes, coordinating routing decisions through a shared reward mechanism to achieve proactive optimization of link loads.At the same time, leveraging the flexibility of SR, segment identifier lists are dynamically adjusted to quickly reroute partial traffic, reducing local link utilization and avoiding potential congestion.Simulation experiments based on real network topologies show that when the proportion of SR key nodes is in the range of 0.3~0.5, the SROD-LC algorithm exhibits significant optimization effects, reducing the network′s maximum link utilization by 21%~35% compared to baseline algorithms.

To further optimize the hardware offloading of collective communication based on the network interface card in the "Tianhe" network, and to support more types of collective communication algorithms and larger message sizes, the order-preserving triggering mechanism and data buffering method for collective communication hardware offloading was investigated.An order-preserving triggering mechanism for concurrent multitasking was proposed, which meets the desired semantics of collective communication and ensures the reproducibility of floating-point computation results.A dynamic network data buffering method based on Hash tables and pulsed credit flow control was proposed to alleviate the contradiction between limited hardware buffering resources and the high demand for buffering a large amount of network data from concurrent multitasking.Experimental results show that compared with software-based collective communication operations, this method can support the hardware offloading of various algorithms for several typical collective communication operations, with significant performance improvement. Meanwhile, the hardware implementation cost is low, especially with high utilization of buffering resources.

Particle transport simulations using stochastic methods face significant challenges on conventional von Neumann architectures, particularly due to random branching events and irregular memory access patterns.These limitations stem from the fundamental mismatch between probabilistic algorithms and deterministic computing paradigms.To bridge the gap between architecture and algorithms, a probabilistically tunable true random number generator was developed based on spintronic and ferroelectric devices.The physical randomness of spintronic devices was leveraged to provide a physical random source for the architecture, and the throughput of random bits was enhanced through optimized control logic and writing mechanisms.Next, programmable synapses were designed based on the memristive properties of ferroelectric devices, enabling nonvolatile continuous weight storage with tunable probabilities.The experimental results indicate that the proposed approach achieves performance improvements ranging from 171 to 1028 times compared to a general-purpose CPU when solving a sample transport problem.Furthermore, compared to existing spin-transfer torque magnetic tunnel junction based true random number generators, the developed method not only enables tunable probability random sampling but also achieves a throughput of 303 Mbit/s when generating uniformly distributed random sequences.
