Yanliang Li is a leading figure in the engineering field at China State Railway Group Co., Ltd, holding the professional title of research fellow. He has been long engaged in research and practical application in the fields of railway ecological environment protection, noise and vibration control, and comprehensive utilization of clean energy. His relevant research achievements have won 6 provincial and ministerial-level science and technology awards, 7 invention patents, and 10 technical awards from the China Academy of Railway Sciences.
Outline
This study solves the key problem that the static level monitoring is susceptible to temperature interference and affects the accuracy in slope instability/deformation monitoring. The purpose is to develop a reliable temperature compensation method for the system, improve the accuracy of slope stability monitoring and provide support for improving the safety and safety monitoring of engineering spoil slope and other projects.
Combined with theoretical analysis and experimental verification, the temperature compensation method is explored. The working principle of the hydrostatic leveling monitoring system is analyzed and the data processing formula, the temperature error calculation formula and the calculation formula for eliminating the error settlement value are derived. The temperature compensation method is established and verified by the field test of the engineering spoil slope which is disturbed by a debris flow.
The experimental results show that this method can reduce the error of the static level monitoring system by about 40 %. The field test shows that the fluctuation of slope settlement monitoring value is reduced after temperature compensation and the monitoring value is consistent with the actual situation, which has certain practicability.
The originality of this study is to derive a theoretical formula for quantifying/eliminating temperature errors in static leveling and to establish a practical temperature compensation method. The accuracy of the system is improved, which provides a reference for slope stability monitoring under complex environment (especially railway geotechnical engineering) and promotes the development of precision monitoring technology.
PDF
2
0
| 科 Family | 属数 Number of genus | 种数 Number of species | 占总种数比例 Percentage of total species (%) | 属 Genus | 种数 Number of species | 占总种数比例 Percentage of total species (%) |
|---|---|---|---|---|---|---|
| 鹅膏菌科Amanitaceae | 2 | 11 | 5.26 | 鹅膏菌属 Amanita | 10 | 4.78 |
| 小菇科 Mycenaceae | 2 | 12 | 5.74 | 丝盖伞属 Inocybe | 5 | 2.39 |
| 多孔菌科 Polyporaceae | 8 | 14 | 6.70 | 蜡蘑属 Laccaria | 5 | 2.39 |
| 红菇科 Russulaceae | 3 | 23 | 11.00 | 小皮伞属 Marasmius | 6 | 2.87 |
| 小菇属 Mycena | 11 | 5.26 | ||||
| 光柄菇属 Pluteus | 5 | 2.39 | ||||
| 红菇属 Russula | 17 | 8.13 | ||||
| 栓菌属 Trametes | 5 | 2.39 |
