Tao Xin was awarded his Ph.D degree from Beijing Jiaotong University, where he currently serves as a professor. His scholarly work centers on addressing critical challenges in railway track dynamics, continuous welded rail and vibration reduction track. He won the first-class prize of National Scientific and Technological Progress Award in 2017.
Outline
The precast concrete slab track (PST) has advantages of fewer maintenance frequencies, better smooth rides and structural stability, which has been widely applied in urban rail transit. Precise positioning of precast concrete slab (PCS) is vital for keeping the initial track regularity. However, the cast-in-place process of the self-compacting concrete (SCC) filling layer generally causes a large deformation of PCS due to the water-hammer effect of flowing SCC, even cracking of PCS. Currently, the buoyancy characteristic and influencing factors of PCS during the SCC casting process have not been thoroughly studied in urban rail transit.
In this work, a Computational Fluid Dynamics (CFD) model is established to calculate the buoyancy of PCS caused by the flowing SCC. The main influencing factors, including the inlet speed and flowability of SCC, have been analyzed and discussed. A new structural optimization scheme has been proposed for PST to reduce the buoyancy caused by the flowing SCC.
The simulation and field test results showed that the buoyancy and deformation of PCS decreased obviously after adopting the new scheme.
The findings of this study can provide guidance for the control of the deformation of PCS during the SCC construction process.
PDF
1
0
| 科 Family | 属数 Number of genus | 种数 Number of species | 占总种数比例 Percentage of total species (%) | 属 Genus | 种数 Number of species | 占总种数比例 Percentage of total species (%) |
|---|---|---|---|---|---|---|
| 鹅膏菌科Amanitaceae | 2 | 11 | 5.26 | 鹅膏菌属 Amanita | 10 | 4.78 |
| 小菇科 Mycenaceae | 2 | 12 | 5.74 | 丝盖伞属 Inocybe | 5 | 2.39 |
| 多孔菌科 Polyporaceae | 8 | 14 | 6.70 | 蜡蘑属 Laccaria | 5 | 2.39 |
| 红菇科 Russulaceae | 3 | 23 | 11.00 | 小皮伞属 Marasmius | 6 | 2.87 |
| 小菇属 Mycena | 11 | 5.26 | ||||
| 光柄菇属 Pluteus | 5 | 2.39 | ||||
| 红菇属 Russula | 17 | 8.13 | ||||
| 栓菌属 Trametes | 5 | 2.39 |
