The Suizhou meteorite: A treasure trove of high-pressure minerals
收藏切换
PDF
Xiande Xie1, Luca Bindi2, Ming Chen1, Xiangping Gu3
Acta Geochimica | 2025, 44(5) : 1059 - 1073
Less
收藏切换
Acta Geochimica | 2025, 44(5): 1059-1073
• REVIEW ARTICLE •
The Suizhou meteorite: A treasure trove of high-pressure minerals
Full
Xiande Xie1, Luca Bindi2, Ming Chen1, Xiangping Gu3
Affiliations
  • 1Key Laboratory of Mineralogy and Metallogeny/Guangdong Provincial Key Laboratory of Mineral Physics and Materials, Guangzhou Institute of Geochemistry, Chinese Academy of Sciences, Guangzhou 510640, China
  • 2Dipartimento di Scienze della Terra, Università degli Studi di Firenze, Via La Pira 4, 50121 Florence, Italy
  • 3School of Geomology and Mineral Resources, Jiangxi Institute of Applied Science and Technology, Nachang 330100, China
Published: 2025-04-09 doi: 10.1007/s11631-025-00774-x
Outline
收藏切换

The Suizhou meteorite is a heavily shock-metamorphosed L6 chondrite which contains thin shock melt veins. So far, 26 high-pressure phases have been identified from the meteorite. Among the high-pressure phases, ten of them were approved as new minerals which include tuite, xieite, wangdaodeite, chenmingite, hemleyite, poirierite, asimowite, hiroseite, elgoresyite, and ohtaniite, by the Commission on New Minerals, Nomenclature and Classification of the International Mineralogical Association. Other high-pressure phases identified from the meteorite are ahrensite, akimotoite, bridgmanite, lingunite, magnesiowüstite, majorite, majorite–pyropess, maskelynite, riesite, ringwoodite, wadsleyite, and 5 other phases including phase A, vitrified phase B and phase C, phase D (Ca-rich majorite), and partly inverted ringwoodite. The occurrence and abundance of high-pressure phases makes this meteorite the one with the richest variety of high-pressure minerals to date.

Suizhou meteorite  /  Chondrite  /  Shock melt vein  /  Phase transition  /  High-pressure mineral
Xiande Xie, Luca Bindi, Ming Chen, Xiangping Gu. The Suizhou meteorite: A treasure trove of high-pressure minerals[J]. Acta Geochimica, 2025 , 44 (5) : 1059 -1073 . DOI: 10.1007/s11631-025-00774-x
Full Text
Less
1　Introduction
Less
Most of the high-pressure minerals are present in the Earth's deep mantle, but this makes it impossible to collect such minerals. The maximum depth attainable by deep borehole drilling is only ~12 km (Fuchs et al. 1990). In rare cases, a few high-pressure minerals were observed as tiny inclusions in diamond from kimberlite tubes (Moore and Gurney 1985; Tschauner et al. 2020), or in lherzolite xenoliths within mantle rocks (Xie et al. 1990; Collerson et al. 2000). Meanwhile, natural high-pressure minerals have been found mostly in extraterrestrial materials, namely, in shocked meteorites (Xie et al. 2001a, 2001b; Xie and Chen 2016; Chen and Xie 2000; Tomioka and Miyahara 2017; Miyahara et al. 2021) and impact craters (Chao et al 1960, 1962; Xie 1973; Chao and Xie 1989, 1990; Chen et al. 2010a, 2010b, 2019). It has been discovered that the L6 chondrites, such as Suizhou, Sixiangkou, Tenham, and Peace River, and the Martian meteorites, such as Tissint, Shergotty, and Zagami, contain abundant high-pressure phases (Xie et al. 2023; Chen et al. 1996; Ma et al. 2018, 2019a, 2019b).
The Suizhou meteorite is an L6 chondrite, and fell on April 15, 1986, at Dayanpo, Suizhou City, Hubei Province, China. The meteorite consists of olivine, low-Ca pyroxene, diopside, plagioclase, FeNi-metal, troilite, merrillite, chlorapatite, chromite, ilmenite, pyrophanite, native copper, and shenzhuangite (Xie et al. 2001a, 2011b; Xie and Chen 2016; Bindi and Xie 2018). The shock classification of the meteorite is S5 and an extensive transformation of plagioclase to maskelynite has been identified (Xie et al. 2001a; 2011a).
This meteorite contains a few very thin shock-produced melt veins of 100–300 μm in width (Fig. 1), and up to 26 high-pressure phases have been identified within or adjacent to the melt veins. These high-pressure phases belong to two assemblages (Chen et al. 1996; Xie et al. 2000). One is a coarse-grained mineral assemblage formed through solid-state phase transition, in which the produced high-pressure minerals include ringwoodite, wadsleyite, poirierite, elgoresyite, asimowite, ahrensite, majorite, akimotoite, bridgmanite, ohtaniite, hemleyite, hiroseite, lingunite, tuite, xieite, chenmingite, wangdaodeite, riesite (TiO2-II), orthorhombic (Ca,Mg)-perovskite, vetrified (Mg,Ca,Fe)SiO3-perovskite, vetrified (Mg,Ca)SiO3 perovskite, and (Mg,Ca)SiO3-majorite. The other is a fine-grained mineral assemblage (vein matrix) crystallized from shock-induced dense melt, in which the produced high-pressure minerals include majorite-pyrope, magnesiowüstite, cryptocrystalline ringwoodite, and partly inverted ringwoodite (Xie and Chen 2016; Xie and Gu 2023; Xie et al. 2001a, 2001b, 2002a, 2002b, 2003, 2011a, 2011b, 2016a, 2016b, 2020, 2023; Chen and Xie 2015; Chen et al. 2003a, 2003b, 2008; Bindi et al. 2017, 2019, 2020, 2021, 2024; Ma et al. 2018, 2019a, 2019b; Tomioka and Miyahara 2017; Tschauner et al. 2020; Tomioka et al. 2021). Among the coarse-grained high-pressure minerals, ten of them have been approved as new minerals by the Commission on New Minerals, Nomenclature and Classification (CNMNC). High-pressure phase transitions in silicate, oxide, and phosphate minerals have been observed in the Suizhou meteorite. This paper reviews the occurrences of high-pressure phases in this meteorite.
2　High-pressure minerals formed through solid-state transition
Less
2.1　High-pressure polymorphs of (Mg,Fe)2SiO4 forsterite
Olivine, (Mg,Fe)2SiO4, is one of the major constituents in chondritic meteorites. In the Suizhou meteorite, the high-pressure polymorphs of olivine (forsterite, α-phase) include wadsleyite (β-phase), ringwoodite (γ-phase), and poirierite (ε-phase).
2.1.1　 Ringwoodite
Natural γ-(Mg,Fe)2SiO4 is a spinel-structured polymorph of olivine. It was first reported by Binns et al. (1969) within black shock veins in the Tenham L6 chondrite, and was named as ringwoodite after the name of Australian petrologist, A. E. Ringwood. The Suizhou polycrystalline grains of ringwoodite of 10–50 μm in length are smooth, rounded, and unfractured. They occur within the shock melt veins of this meteorite (Fig. 2). The ringwoodite grains have the same chemical composition as olivine in unmelted chondritic rock (Xie and Chen 2016). This indicates that these ringwoodite grains must have formed directly from olivine through solid-state phase transformation under high pressures.
2.1.2　 Wadsleyite
Natural β-(Mg,Fe)2SiO4 is a spinelloid-type polymorph of olivine. It was firstly discovered in the shock veins of the Tenham and Peace River L6 chondrites (Putnis and Price 1979). This high-pressure silicate mineral was named wadsleyite, after A. D. Wadsley. by Price et al. (1983). In the Suizhou meteorite, Fe-poor (FeO up to 1.50 wt%) and Fe-rich (FeO up to 6.0 wt%) wadsleyites were observed in its shock melt veins (Bindi et al. 2024). They occur in association with ohtaniite, MgSiO3 glass and FeNi metal (Fig. 3). X-ray diffraction analyses have revealed that both Fe-poor and Fe-rich wadsleyite exhibit the classic features observed in the crystal structure of normal wadsleyite.
2.1.3　 Poirierite
The presence of ε-(Mg,Fe)2SiO4, a high-pressure polymorph of olivine with a structure intermediate between olivine, ringwoodite, and wadsleyite, was theoretically predicted by Madon and Poirier (1983). Natural ε-(Mg,Fe)2SiO4 was first found in the shock melt veins of the Suizhou, Tenham, and Miami L6 chondrites by Tomioka et al. (2021). In the Tenham meteorite, this ε-phase occurs as nanoscale lamellae coherently intergrown in ringwoodite grains. In the Suizhou meteorite, it occurs as tiny grains and veinlets within ringwoodite grains (Fig. 4). This ε-(Mg,Fe)2SiO4 was named poirierite after Dr. Jean-Paul Poirier, in honor of his contributions to mineral physics, including the theoretical prediction of the ε-Mg2SiO4 phase. It was proposed that poirierite was formed during rapid decompression at relatively low temperature in retrograde shock metamorphism of these meteorites.
2.2　A special high-pressure (Mg,Fe)-silicate—elgoresyite
A high-pressure polymorph of other (Fe,Mg)-silicate with the composition (Mg,Fe)5Si2O9 was discovered in a shock melt vein of the Suizhou meteorite, and was named elgoresyite after A. El Goresy (Bindi et al. 2021). It occurs as a very rare, subhedral μm-sized crystal closely associated with ringwoodite, taenite, in a MgSiO3 glass (Fig. 5). The crystal structure of this (Fe,Mg)-silicate is the same as the iron oxide, Fe7O9, strongly suggesting that silicates also form the [(Mg,Fe)O]m+n(SiO2)n series which are isostructural to iron oxides via (Mg2+, Fe2+) + Si4+ = 2Fe3+ substitution. This (Fe,Mg)-silicate is thought to be a potential constituent mineral in rocky planets with relatively high MgO + FeO content.
2.3　High-pressure polymorphs of (Fe,Mg)2SiO4 fayalite
The high-pressure polymorphs of fayalite (α-phase) include asimowite (β-phase,) and ahrensite (γ-phase). Both asimowite and ahrenside were discovered within a shock melt vein of the Suizhou meteorite (Bindi et al. 2019, 2020).
2.3.1　 Ahrensite
The silicate, γ-Fe2SiO4 phase, is the spinel-structured polymorph of fayalite. Natural γ-Fe2SiO4 was discovered in the shock-melt vein of the Umbarger L6 ordinary chondrite (Xie et al. 2002a, 2002b). It was also observed in the melt-pocket of the Tissint Martian meteorite and named ahrensite after T. Ahrens (Ma et al. 2016). In the Suizhou meteorite, ahrensite occurs as solid-solution grains with ringwoodite within its shock melt veins (Bindi et al. 2020). Ahrensite in this solid solution has the composition of (Fe2+0.91Mg0.85Al0.06Ca0.06Na0.05)Si1.01O4. This solid solution exhibits the normal spinel structure, with Fe(Mg) in the octahedral A site and Si in the tetrahedral B site. Its associate minerals are Fe-bearing periclase, hiroseite, and MgSiO3 glass (Fig. 6).
2.3.2　 Asimowite
The silicate β-Fe2SiO4 phase is the spinelloid-structured polymorph of fayalite. The natural β-Fe2SiO4, a mineral with Fe dominance over Mg in the octahedral sites, was found as inclusions in the shock-induced FeNi droplets of the Suizhou meteorite and the Quebrada Chimborazo 001 CB carbonaceous chondrite, and was named asimowite after P. D. Asimow (Bindi et al. 2019). Asimowite is also found in the Suizhou meteorite as round inclisions in FeNi metal (Fig. 7) and it is chemically homogeneous, and its empirical formula is (Fe2+1.10Mg0.80Cr3+0.04Mn2+0.02Ca0.02Al0.02Na0.01)Σ=2.01(Si0.97Al0.03)Σ=1.00O4 (Fig. 7).
2.4　High-pressure polymorphs of (Mg,Fe)SiO3 orthopyroxene
At high pressure and temperature, low-calcium (Mg,Fe)SiO3 orthopyroxene transforms to high-pressure polymorphs including majorite, akimotoite, perovskite (bridgmanite), and ohtaniite, an unusual Mg–silicate of MgSiO3 composition, but with an Mg2SiO4 wadsleyite structure. The spatial relationship between the composed grains of pyroxene, akimotoite, and vitrified perovskite was observed in the Suizhou meteorite (Fig. 8), which demonstrates a temperature gradient from the shock melt vein to the chondritic portion.
2.4.1　 Majorite
Majorite is the high-pressure polymorph of low-calcium pyroxene (Mg,Fe)SiO3 with a garnet structure. The first natural occurrence of majorite within a veinlet in the Coorara meteorite was reported by Smith and Mason (1970), and was named majorite after the name of Australian petrologist, A. Major. Polycrystalline grains of majorite occur in the shock melt veins of the Suizhou meteorite with the grain sizes ranging from 8 to 50 μm in diameter (Figs. 2, 9). These grains are also smooth and unfractured. Electron microprobe analyses show that the Suizhou majorite has the same chemical composition as the low-Ca pyroxene outside the veins, indicating that the Suizhou majorite is formed from low-Ca pyroxene through solid-state phase transition under high pressures (Xie and Chen 2016).
2.4.2　 Akimotoite
Akimotoite is the high-pressure polymorph of low-calcium pyroxene (Mg,Fe)SiO3 with ilmenite structure. Natural (Mg,Fe)SiO3-ilmenite was found in the Acfer 040 (L5-6) chondrite (Sharp et al. 1997), and then approved as a new mineral with the mineral name akimotoite (Tomioka and Fujino 1999). Shock-produced akimotoite was also identified in the Suizhou meteorite, which occurs in two kinds (Chen and Xie 2015). The first is the zonal polycrystalline aggregates of akimotoite in shocked pyroxene grains close to the shock vein, where akimotoite occurs in a zonal area in between pyroxene and MgSiO3-glass as irregular small clumps up to 5 μm in size (Fig. 8). The second is the irregular layers of akimotoite up to 4 μm in thickness occurring in fractures and cracks of low-Ca pyroxene enclosed in the shock veins (Fig. 10). This occurrence suggests a solid-state transformation mechanism of pyroxene to akimotoite, and that akimotoite should have nucleated, and grew in the area with abundant defects caused by shock deformation because the defect significantly enhances the solid-state reactivity and the kinetics of nucleation of high-pressure phase (Chen and Xie 2015).
2.4.3　 Vitrified perovskite (bridgmanite)
The natural perovskite-structured (Mg,Fe)SiO3 phase with an orthorhombic symmetry was first identified in the Tenham L6 ordinary chondrite (Tomioka and Fujino 1999). A fine-grained assemblage of amorphous (Mg,Fe)SiO3 phase plus akimotoite was found in the shock vein matrix of the Acfer 040 meteorite (Sharp et al. 1997). Fine-scale intergrowth of (Mg,Fe)SiO3-perovskite and magnesiowüstite, as post-ringwoodite dissociation products of olivine, were also found in the shergottite DaG 735 (Miyahara et al. 2011a, 2011b). The mineral was named bridgmanite after P. W. Bridgman (Tschauner et al. 2014). The vitrified (Mg,Fe)SiO3 perovskite phase was observed in shock melt veins of the Suizhou meteorite (Chen et al. 2004). The ovoid grains of this phase are closely associated with ringwoodite and majorite and surrounded by a fine-grained vein matrix composed of majorite-pyrope garnet, ringwoodite, magnesiowüstite, metal, and troilite (Fig. 11). Heating experiments and the molecular- and lattice dynamics calculations indicated that the crystalline MgSiO3 perovskite would be decompressed to an amorphous phase near the ambient pressure from its high-pressure stability fields (Durben and Wolf 2008; Hemmati et al. 1995). Hence, the formation of vitrified (Mg,Fe)SiO3 in the Suizhou shock veins is interpreted to have amorphized from perovskite after pressure release (Chen et al. 2004).
2.4.4　 Ohtaniite
The natural high-pressure silicate phase with a composition close to that of a pyroxene but with wadsleyite structure was discovered in a shock melt pocket of the Suizhou meteorite, and named ohtaniite in honor of Eiji Ohtani (Bindi et al. 2024). This unusual mineral occurs as tiny irregular grains in the MgSiO3 melt, and is associated with Fe-poor and Ferich wadsleyite and FeNi metal (Fig. 12). Electron microprobe analyses of this mineral gave the empirical formula (based on 8 oxygen atoms pfu) [(Mg2.73Fe2+0.14Na0.03Al0.03Ca0.02Si0.05)Σ3.00(Si0.49□0.51)Σ1.00]Si2O8, ideally Mg3(Si0.5□0.5)Si2O8. Single-crystal X-ray studies showed the mineral to be orthorhombic, space group Imma (#74), with the unit-cell parameters: a = 5.5820(10), b = 11.418(3), c = 7.708(2) Å, V = 491.3(2) Å3, and Z = 4. a = 5.5820(10), b = 11.418(3), c = 7.708(2) Å, V = 491.3(2) Å3, and Z = 4. This indicates that ohtaniite has the structure of wandsleyite, a polymorph of Mg2SiO4 olivine. Hence, the finding of ohtaniite expands our understanding of shock-induced mineralogical transformations in extraterrestrial materials.
2.5　High-pressure polymorphs of (Fe,Mg)SiO3 ferrosilite
At high pressure and high temperature, the (Fe,Mg)SiO3 ferrosilite transforms to ilmenite-structured hemleyite and perovskite-structured hiroseite. Both these high-pressure minerals have been discovered for the first time in shock melt veins of the Suizhou meteorite (Bindi et al. 2017, 2020).
2.5.1　 Hemleyite
The natural ilmenite-structured (Fe,Mg)SiO3 phase with Fe/(Mg + Fe) = 0.56 was discovered in an unmelted portion of the shocked Suizhou meteorite (Fig. 13). The mineral was named hemleyite after R. J. Hemley (Bindi et al. 2017). It was associated with olivine, Fe-rich clinoenstatite, and surrounded by Fe-poor clinoenstatite, which implies that the Fe-rich clinoenstatite belongs to a kind of secondary pyroxene likely formed from olivine and pyroxene by replacement of Fe-rich materials during the thermal metamorphism of the meteorite.
2.5.2　 Hiroseite
The natural perovskite-structured polymorph of (Fe,Mg)SiO3 phase with Fe/(Mg + Fe) = 0.59 was discovered in the shock melt veins of the Suizhou meteorite (Bindi et al. 2020). It occurs as tiny grains within Fe-periclase which is surrounded by a solid solution of ringwoodite and ahrensite and MgSiO3 glass (Fig. 6). The mineral was named hiroseite after K. Hirose. It has been revealed that this crystalline Fe-rich bridgmanite with a Fe3+/(Fe2+ + Fe3+) ratio of 0.1–0.2 is coexisting with nanocrystalline metallic iron. Thus providing the first evidence for a subsolidus charge disproportionation reaction in natural high-pressure minerals: 3Fe2+ → Feº + 2Fe3+ (Bindi et al 2020).
2.6　High-pressure polymorphs from breakdown of diopside
Diopside is a monoclinic pyroxene mineral of CaMgSi2O6 composition The results of many experiments performed on diopside at pressure ranges of 18–50 GPa and 1000–1900 °C showed that the diopside had finely broken down into cubic CaSiO3–perovskite and orthorhombic MgSiO3–perovskite, and one of the intermediate products is (Mg,Ca)SiO3 garnet, the Ca-rich Mg-majorite (Xie and Gu 2023). Fortunately, a shock-metamorphosed diopside grain associated with ringwoodite and lingunite was found in a shock melt vein of the Suizhou meteorite (Fig. 14). The chemical formation of this shock-metamorphosed diopside is (Ca0.419Mg0.466Fe0.088Ti0.007Cr0.018Na0.024)1.022(Si0.977Al0.014)0.991. The detailed micro-mineralogical analyses revealed four high-pressure silicate phases with different compositions and structures within this diopside grain, termed phase A, vitrified phase B and phase C, and phase D (Xie and Gu 2023).
2.6.1　 Phase A—the orthorhombic (Ca0.663–Mg0.314)SiO3-perovskite
Phase A is the main breakdown product of diopside in the Suizhou melt vein upon shock. It has a rounded shape and gray color with a smooth surface, and is closely associated with phase B (Fig. 15a). Phase A has been identified as orthorhombic perovskite (Xie and Gu 2023), which is different with the cubic CaSiO3-perovskite–davemaoite (Tschauner et al. 2021). The chemical formula of phase A is (Ca0.663Mg0.314)0.977(Si0.982Al0.06)0.988O3, and its simplified formula is (Ca,Mg)SiO3. The atom units of Ca in phase A is as twice larger than that of Mg, and phase A does not contain FeO (Xie and Gu 2023).
2.6.2　 Vitrified phase B—the (Mg0.642Ca0.290Fe0.098)SiO3 perovskite
Phase B is also a main breakdown product of the shocked diopside in the shock melt veins of the Suizhou meteorite. It is of irregular or ladder shape and light color, and occurs around or in the interstices of phase A grains (Xie and Gu 2023). Because of the volume shrinkage during cooling and solidification, some fractures/cracks crosscutting their grains are observed (Fig. 15a). Electron diffraction analysis revealed that phase B is an amorphized phase. The chemical formula of this phase is (Mg0.642Ca0290Fe0.098Ti0.001Na0.024Cr0.005)1.060(Si0.967Al0.043)1.010O3, and its simplified formula is (Mg,Ca,Fe)SiO3. FeO content (6.48 wt%) in phase B is a litter higher than diopside (5.40–5.71 wt%) in the chondritic portion of the Suizhou meteorite. Based on the close association of phase B with phase A, and the results of heating experiments of crystalline MgSiO3 perovskite (Durben and Wolf 2008; Hemmati et al. 1995), it has been assumed that phase B is the vitrified (Mg0.642Ca0.290Fe0.098)SiO3 perovskite.
2.6.3　 Vitrified phase C—the Ca-rich Mg-perovskite with a (Mg0.853Ca0.167)SiO3 composition
Phase C is the third breakdown product of the shock-metamorphosed diopside in the Suizhou meteorite. It has an irregular shape and light gray color. Some volume shrinkage-produced fractures/cracks are also observed (Fig. 15b). Electron diffraction analysis revealed that phase B is also an amorphized phase. The chemical formula of the phase C is (Mg0.853Ca0.167Ti0.001Na0.023Cr0.004)1.048(Si0.949Al0.041)0.990O3, and its simplified formula is (Mg,Ca)SiO3. Although the atom units of Mg in phase C are 5 times larger than those of Ca, the Ca content is still rich enough (CaO = 8.70 wt%), and phase C does not contain FeO (Xie and Gu 2023). It has been identified that phase C in the Suizhou shock-metamorphosed diopside is a vitrified Ca-rich Mg-perovskite with (Mg0.853Ca0.167)SiO3 composition.
2.6.4　 Phase D—the Ca-rich majorite with (Mg0.578Ca0.414)SiO3 composition
Phase D is the fourth breakdown product of shocked diopside in the Suizhou meteorite. It has an irregular or granular shape and dark gray color (Fig. 15b). Phase D grains are commonly surrounded by glassy phase C. The chemical formula of phase D is (Mg0.578Ca0.414Cr0.010)1.002(Si0.981Al0.020)1.001O3, and its simplified formula is (Mg,Ca)SiO3. The atom unit of Mg in phase D is just a little larger than that of Ca, and phase D does not contain FeO (Xie and Gu 2023). The Raman spectra of phase D spectra can be compared with that of majorite, the (Mg,Fe)SiO3-garnet in the shock melt vein of Suizhou meteorite (Xie et al. 2001a). It has been assumed that the phase D is (Mg,Ca)SiO3 majorite with (Mg0.578Ca0.414)SiO3 composition (Xie and Gu 2023).
2.7　High-pressure polymorphs of plagioclase
2.7.1　 Lingunite
Hollandite-type NaAlSi3O8, the high-pressure polymorph of plagioclase, was first discovered in the shock-melt veins of the Sixiangkou chondrite (Gillet et al. 2000), and was named lingunite after L. G. Liu (Liu and El Gorsey 2007). NaAlSi3O8-hollandite was also identified in the shock melt veins of the Suizhou meteorite (Xie et al. 2001b). Lingunite in the Suizhou meteorite has a dark color and irregular shape, and its grains are smooth and unfractured, with grain sizes ranging from 8 to 25 μm in diameter (Figs. 2, 9, 14). Its chemical composition is similar to that of plagioclase. However, this shock-induced high-pressure phase in veins has slightly higher FeO, MgO, and Na2O contents and lower K2O content than those of its host plagioclase.
2.7.2　 Maskelynite
The first identification of a dense plagioclase glass is from the shergottite Shergotty and has been called maskelynite after N. S. Maskelyne (Tschermak 1872). This maskelynite has a non-vesicular flow texture resulting from melting and liquid migration followed by solidification. Stöffler et al. (1986) observed some dense plagioclase glass that still retains the morphology of the original plagioclase but loses its crystallinity. Maskelynite has been commonly found in the Suizhou meteorite (Xie et al. 2001a), and both types of maskelynite occurrence were observed under a microscope and on BSE images. Figure 16 clearly demonstrates these two occurrence types in the chondritic portion of Suizhou meteorite.
2.8　High-pressure polymorphs of Ca-phosphates
Calcium phosphates are another group of common accessory minerals in meteorites. The most common phosphates in chondrites are merrillite and apatite. It was found that both merrillite and apatite could transform to the high-pressure phase, tuite, under pressure (Xie et al. 2003, 2013).
2.8.1　 Tuite transformed in solid state from merrillite
The high-pressure γ-Ca3(PO4)2 phase was synthesized by Murayama et al. (1986). The natural γ-Ca3(PO4)2 phase transformed in solid state from merrillite was found in the shock melt vein of the Suizhou meteorite (Xie et al. 2002a, 2002b), and was named tuite after G. C. Tu (Xie et al. 2003). Two types of tuite occurrence were observed (Xie et al. 2002a, 2002b, 2016a). The first one is in the form of a single grain with round outline occurring within shock melt veins (Fig. 2). This type of tuite occurs as small polycrystalline grains in association with some other high-pressure mineral in the veins. The other is formed through partial decomposition of merrillite. This type of tuite occurs as a narrow band directly adjacent to the wall of a shock vein (Fig. 17). Tuites of both types contain small contents of Na2O and MgO, but do not contain Cl.
2.8.2　 Tuite formed through decomposition of chlorapatite
Two tuite grains have been identified as a consequence of the high-pressure decomposition of chlorapatite, 2Ca5(PO4)3Cl → 3γ-Ca3(PO4)2 + CaCl2, in a shock vein of the Suizhou meteorite (Xie et al. 2013). The larger grain measures approximately 20 × 35 μm, and the smaller one approximately 10 × 20 μm (Fig. 18). These two grains do not exhibit fractures and are gray in color under reflected light. In addition, the partial decomposition of chlorapatite makes the second occurrence of tuite in the Suizhou meteorite (Xie et al. 2016a), i.e., as a narrow band or a nodule directly adjacent to the wall of a shock vein (Figs. 17, 19). In opposition to the tuites transformed from merrillite, tuites formed through decomposition of chlorapatite do not contain Na2O and MgO, but contain a small amount of Cl.
2.9　High-pressure polymorphs of oxides
The main extraterrestrial oxide minerals occurring in meteorites are chromite, ilmenite, and rutile. All these oxide minerals could transform to their high-pressure phases, respectively, by shock-loading. Fortunately, high-pressure polymorphs of these three oxide minerals, namely, xieite, wangdaodeite, and riesite (TiO2-II) were discovered in the Suizhou meteorite (Chen et al. 2003b; Ma et al. 2019a; Xie et al. 2023).
2.9.1　 Xieite
CaTi2O4-type FeCr2O4 phase, a postspinel high-pressure polymorph of chromite, was synthesized by Chen et al. (2003a), and natural CaTi2O4-type FeCr2O4 phase was discovered in the shock melt veins of the Suizhou meteorite (Chen et al. 2003b). This mineral was named xieite after X. D. Xie (Chen et al. 2008). It occurs in association with other high-pressure minerals including ringwoodite, majorite, and lingunite (Fig. 20). Xieite occurs as compact polycrystalline aggregates of about 5−40 μm in grain size and commonly displays as a pseudomorph of chromite crystals or its fragments (Xie et al. 2011b). The aggregates are composed of crystallites of less than 1 μm in size. The chemical composition of xieite is the same as FeCr2O4 chromite. The P–T condition for the formation of xieite is estimated to be 18–23 GPa and 1800–1950 °C, respectively.
2.9.2　 Chenmingite
The Café2O4-type FeCr2O4 phase, the second postspinel high-pressure polymorph of chromite, was also synthesized by Chen et al. (2003b). The natural Café2O4-type FeCr2O4 phase was first discovered within a shock-metamorphosed chromite grain inside the Suizhou meteorite (Chen et al. 2003b). This mineral was then found within a chromite grain of the Tissint Martian meteorite, and named chenmingite after M. Chen (Ma et al. 2019a). Chenmingite in the Suizhou meteorite occurs as lamella-like slices associating with a chromite matrix, where two–three sets of slices are observed (Fig. 21). The high P–T experiments demonstrate that chenmingite is indeed a quenchable polymorph of chromite formed above 12.5 GPa at temperature lower than that for xieite.
2.9.3　 Wangdaodeite
The natural lithium-niobate structured phase of ilmenite FeTiO3 was discovered in shock melt veins or in the area adjacent to shock veins of the Suizhou meteorite, and named wangdaodeite after D. D. Wang (Xie et al. 2020). The polycrystalline wangdaodeite occurs as micro-sized granular grains 2–18 μm in size, composed of nanomeritic crystals of 10–80 nm. In contrast to the fractured ilmenite grains outside the veins, no microstructures were observed inside the wangdaodeite grains (Fig. 22). Wangdaodeite is isochemical to and structurally close to its host FeTiO3 ilmenite. The essential difference is in space group: wangdaodeite is R3c and ilmenite is R-3. The P–T conditions for formation of wangdaodeite were estimated to be 20–24 GPa and > 1200 °C.
2.9.4　 Riesite (TiO2-II)
Riesite (TiO2-II) is the α-PbO2-structured high-pressure phase of rutile. Natural TiO2-II was previously found in ultrahigh-pressure metamorphic and mantle-derived rocks, and in tektite. This polymorph of rutile was found in the Ries impact crater (El Goresy et al. 2001), and was named riesite after the name of the location (Tschauner et al. 2020). This high-pressure phase was also discovered in the unmelted rock of the shocked Suizhou meteorite (Xie et al. 2023). It occurs as needle- and leaf-shaped inclusions in ilmenite (Fig. 23), as well as a patch- and tape-shaped body in pyrophanite. The P–T regime estimated for the phase transition of rutile into TiO2-II phase is 20–25 GPa and 1000 °C.
3　High-pressure minerals crystallized from shock melt in veins
Less
The fine-grained vein matrix in the Suizhou meteorite is composed of euhedral garnet crystals with majorite–pyrope composition and irregular grains of magnesiowüstite, and cryptocrystalline ringwoodite, along with eutectic intergrowths of FeNi metal and troilite in the interstices between garnet crystal (Fig. 24) (Xie et al. 2011a, 2016a, 2016b). In addition, a fine-grained partly inverted ringwoodite of (Mg,Fe,Si)2(Si,□)O4 composition was also found in shock veins of the Suizhou meteorite (Ma et al. 2019b).
3.1　Majorite–pyrope garnet
Majorite–pyrope garnet is a major constituent of the Suizhou vein matrix. Most of the idiomorphic garnet crystals had grain size of 1–2 μm, but crystals larger than 6 μm were also observed. Under TEM, the garnet crystals were transparent and no internal microstructures were observed (Fig. 24). In comparison with its precursor pyroxene, the majorite–pyrope garnet showed increased Al2O3 and CaO contents. On the basis of its higher Al2O3 content (3.51 wt%) than that in pyroxene (0.16 wt%), this garnet mineral was identified as majorite–pyrope in solid solution (Xie et al. 2001a).
3.2　Magnesiowüstite (Fe-rich periclase)
Magnesiowüstite, (Mg,Fe)O, is the second most abundant mineral in the vein matrix of Suizhou meteorite. It has an irregular shape, and fills the interstices between majorite–pyrope garnet crystals, implying that magnesiowüstite crystallized after the solidification of garnet in veins (Xie et al. 2001a). Under TEM, this mineral showed a clear polycrystalline nature (Fig. 24). The diameter of the polycrystalline grains ranged from several tens to several hundred nanometers (Xie et al. 2016a, 2016b). The empiric formula of magnesiowüstite was determined to be Wu53–Per47, where Wu is wüstite and Per is periclase.
3.3　Cryptocrystalline ringwoodite
Cryptocrystalline grains of ringwoodite were observed in the shock melt vein of Suizhou meteorite either in the form of narrow independent bands of 2–3 μm in width, or as irregular grains filling the interstices between garnet crystals or garnet and magnesiowüstite grains (Xie et al. 2001a). Under TEM, this type of ringwoodite appeared transparent, but with many microfractures of different directions probably formed by volume shrinkage during cooling (Fig. 24).
3.4　Partly inverted ringwoodite (Mg,Fe,Si)2(Si,□)O4
The fine-grained partly inverted ringwoodite of (Mg,Fe,Si)2(Si,□)O4 composition was observed within the matrix of a shock melt vein along with the finegrained (Mg,Fe)SiO3-phase in the Suizhou meteorite (Ma et al. 2019b). The crystal size is generally in the range of 100–800 nm (Figs. 5, 25). This phase contains 2.23–3.53 wt% of Al2O3, 1.09–2.04 wt% of CaO, and 0.85–1.31 wt% of Na2O, which implies that it crystallized from shock-induced dense silicate melt.
4　Summary
Less
The identification of 26 high-pressure phases in the Suizhou meteorite indicates that this meteorite contains abundant high-pressure minerals in the ordinary chondrites. The abundant production of high-pressure minerals indicates that the impact-triggered temperature and pressure conditions of this meteorite are relatively favorable for the preservation of high-pressure minerals. Among identified 26 high-pressure phases, 11 of them had been previously discovered in other meteorites, 10 of them are new minerals approved by CNMNC of the International Mineralogical Association, and 5 are other phases. The discovery of a large number of different types of high-pressure minerals and phases in the Suizhou meteorite indicates that shock-metamorphosed meteorites are a treasure trove of natural high-pressure minerals.
Funding
Less
  • Science and Technology Planning Project of Guangdong Province(2023B1212060048)
References
Less
Bindi LC, Xie XD (2018) Shenzhuangite, NiFeS2, the Ni-analogue of chalcopyrite from the Suizhou L6 chondrite. Eur J Mineral 30(1):165–169. https://doi.org/10.1127/ejm/2017/0029-2684
Bindi LC, Chen M, Xie XD (2017) Discovery of the Fe-analogue of akimotoite in the shocked Suizhou L6 chondrite. Sci Rep 7:42674. https://doi.org/10.1038/srep42674
Bindi LC, Brenker FE, Nestola F, Koch TE, Prior DJ, Lilly K, Krot AN, Bizzarro M, Xie XD (2019) Discovery of asimowite, the Fe-analog of wadsleyite, in shock-melted silicate droplets of the Suizhou L6 and the Quebrada Chimborazo 001 CB3.0 chondrites. Am Mineral 104(5):775–778. https://doi.org/10.2138/am-2019-6960
Bindi LC, Shim SH, Sharp TG, Xie XD (2020) Evidence for the charge disproportionation of iron in extraterrestrial bridgmanite. Sci Adv 6(2):7893. https://doi.org/10.1126/sciadv.aay7893
Bindi LC, Sinmyo R, Bykova E, Ovsyannikov SV, McCammon C, Kupenko I, Ismailova L, Dubrovinsky L, Xie XD (2021) Discovery of elgoresyite, (Mg,Fe)5Si2O9: implications for novel iron-magnesium silicates in rocky planetary interiors. ACS Earth Space Chem 5(8):2124–2130. https://doi.org/10.1021/acsearthspacechem.1c00157
Bindi LC, Xie ZD, Sharp TG, Xie XD (2024) Unveiling deep earth's hidden potential: insights from a new high-pressure phase discovered in a shocked meteorite. Discov Miner 1(1):1. https://doi.org/10.1007/s44346-024-00001-0
Binns RA, Davis RJ, Reed SJB (1969) Ringwoodite, natural (Mg,Fe)2SiO4 spinel in the tenham meteorite. Nature 221:943–944. https://doi.org/10.1038/221943a0
Chao ECT, Xie XD (1989) Micro-mineralogical techniques in geological investigations. Science Press, Beijing, p 215
Chao ECT, Xie XD (1990) Mineralogical approaches to geological investigations. Science Press, Beijing, p 388
Chao ECT, Shoemaker EM, Madsen BM (1960) First natural occurrence of coesite. Science 132(3421):220–222. https://doi.org/10.1126/science.132.3421.220
Chao ECT, Fahey JJ, Littler J, Milton DJ (1962) Stishovite, SiO2, a very high pressure new mineral from meteor crater, Arizona. J Geophys Res 67(1):419–421. https://doi.org/10.1029/jz067i001p00419
Chen M, Xie XD (2000) Progress in searching natural high-pressure minerals and its significance in the Earth's mantle mineralogy. Geol J China Univ 6(2):121–125. https://doi.org/10.16108/j.issn1006-7493.2000.02.001
Chen M, Xie XD (2015) Shock-produced akimotoite in the Suizhou L6 chondrite. Sci China Earth Sci 58(6):876–880. https://doi.org/10.1007/s11430-014-5039-5
Chen M, Sharp TG, El GoresyWopenka AB, Xie XD (1996) The majorite-pyrope + magnesiowüstite assemblage: constraints on the history of shock veins in chondrites. Science 271(5255):1570–1573. https://doi.org/10.1126/science.271.5255.1570
Chen M, Shu JF, Xie XD, Mao HK (2003a) Natural CaTi2O4-structured FeCr2O4 polymorph in the Suizhou meteorite and its significance in mantle mineralogy. Geochim Cosmochim Acta 67(20):3937–3942. https://doi.org/10.1016/S0016-7037(03)00175-3
Chen M, Shu JF, Mao HK, Xie XD, Hemley RJ (2003b) Natural occurrence and synthesis of two new postspinel polymorphs of chromite. Proc Natl Acad Sci USA 100(25):14651–14654. https://doi.org/10.1073/pnas.2136599100
Chen M, Xie XD, El Goresy A (2004) A shock-produced (Mg,Fe)SiO3 glass in the Suizhou meteorite. Meteorit Planet Sci 39(11):1797–1808. https://doi.org/10.1111/j.1945-5100.2004.tb00076.x
Chen M, Shu JF, Mao HK (2008) Xieite, a new mineral of high-pressure FeCr2O4 polymorph. Chin Sci Bull 53(21):3341–3345. https://doi.org/10.1007/s11434-008-0407-1
Chen M, Xiao WS, Xie XD, Tan DY, Cao YB (2010a) Xiuyan crater, China: impact origin confirmed. Chin Sci Bull 55(17):1777–1781. https://doi.org/10.1007/s11434-010-3010-1
Chen M, Xiao WS, Xie XD (2010b) Coesite and quartz characteristic of crystallization from shock-produced silica melt in the Xiuyan crater. Earth Planet Sci Lett 297(1–2):306–314. https://doi.org/10.1016/j.epsl.2010.06.032
Chen M, Shu JF, Xie XD, Tan DY (2019) Maohokite, a post-spinel polymorph of MgFe2O4 in shocked gneiss from the Xiuyan crater in China. Meteorit Planet Sci 54(3):495–502. https://doi.org/10.1111/maps.13222
Collerson KD, Hapugoda S, Kamber BS, Williams Q (2000) Rocks from the mantle transition zone: majorite-bearing xenoliths from Malaita, southwest Pacific. Science 288(5469):1215–1223. https://doi.org/10.1126/science.288.5469.1215
Durben D, Wolf G (2008) High-temperature behavior of metastable MgSiO3 perovskite: A Raman spectroscopic study. Am Mineral 77:890–893
El Goresy A, Chen M, Dubrovinsky L, Gillet P, Graup G (2001) An ultradense polymorph of rutile with seven-coordinated titanium from the Ries crater. Science 293(5534):1467–1470. https://doi.org/10.1126/science.1062342
Fuchs K, Kozlovsky YA, Krivtsov AI, Zoback MD (1990) Super-deep continental drilling and deep geophysical sounding. Springer, Berlin Heidelberg. https://doi.org/10.1007/978-3-642-50143-2
Gillet P, Chen M, Dubrovinsky L, El Goresy A (2000) Natural NaAlSi3O8-hollandite in the shocked Sixiangkou meteorite. Science 287(5458):1633–1636. https://doi.org/10.1126/science.287.5458.1633
Hemmati M, Chizmeshya A, Wolf GH, Poole PH, Shao J, Angell CA (1995) Crystalline-amorphous transition in silicate perovskites. Phys Rev B 51(21):14841–14848. https://doi.org/10.1103/physrevb.51.14841
Liu LG, El Gorsey A (2007) High-pressure phase transitions of the feldspars, and further characterization of lingunite. Int Geol Rev 49(9):854–860. https://doi.org/10.2747/0020-6814.49.9.854
Ma C, Tschauner O, Beckett JR, Liu Y, Rossman GR, Sinogeikin SV, Smith JS, Taylor LA (2016) Ahrensite, γ-Fe2SiO4, a new shock-metamorphic mineral from the Tissint meteorite: Implications for the Tissint shock event on Mars. Geochim Cosmochim Acta 184:240–256. https://doi.org/10.1016/j.gca.2016.04.042
Ma C, Tschauner O, Beckett JR, Rossman GR, Prescher C, Prakapenka VB, Bechtel HA, MacDowell A (2018) Liebermannite, KAlSi3O8, a new shock-metamorphic, high-pressure mineral from the Zagami Martian meteorite. Meteorit Planet Sci 53(1):50–61. https://doi.org/10.1111/maps.13000
Ma C, Tschauner O, Beckett JR, Liu Y, Greenberg E, Prakapenka VB (2019a) Chenmingite, FeCr2O4 in the CaFe2O4-type structure, a shock-induced, high-pressure mineral in the Tissint Martian meteorite. Am Mineral 104(10):1521–1525. https://doi.org/10.2138/am-2019-6999
Ma C, Tschauner O, Bindi LC, Beckett JR, Xie XD (2019b) A vacancy-rich, partially inverted spinelloid silicate, (Mg,Fe, Si)2(Si,□)O4, as a major matrix phase in shock melt veins of the Tenham and Suizhou L6 chondrites. Meteorit Planet Sci 54(9):1907–1918. https://doi.org/10.1111/maps.13349
Madon M, Poirier JP (1983) Transmission electron microscope observation of α, β and γ(Mg,Fe)2SiO4 in shocked meteorites: planar defects and polymorphic transitions. Phys Earth Planet Inter 33:31–44
Miyahara M, Ohtani E, Ozawa S, Kimura M, El GoresySakai AT, Nagase T, Hiraga K, Hirao N, Ohishi Y (2011) Natural dissociation of olivine to (Mg,Fe)SiO3 perovskite and magnesiowustite in a shocked Martian meteorite. Proc Natl Acad Sci USA 108(15):5999–6003. https://doi.org/10.1073/pnas.1016921108
Miyahara M, Tomioka N, Bindi L (2021) Natural and experimental high-pressure, shock-produced terrestrial and extraterrestrial materials. Prog Earth Planet Sci 8(1):59. https://doi.org/10.1186/s40645-021-00451-6
Moore RO, Gurney JJ (1985) Pyroxene solid solution in garnets included in diamond. Nature 318(6046):553–555. https://doi.org/10.1038/318553a0
Murayama JK, Nakai S, Kato M, Kumazawa M (1986) A dense polymorph of Ca3(PO4)2: a high pressure phase of apatite decomposition and its geochemical significance. Phys Earth Planet Inter 44:293–303
Price GD, Putnis A, Agrell SO, Smith DGW (1983) Wadsleyite, natural beta-(Mg,Fe)2SiO4 from the Peace river meteorite. Can Mineral 21:29–35
Putnis A, Price GD (1979) High-pressure (Mg,Fe)2SiO4 phases in the Tenham chondritic meteorite. Nature 280:217–218. https://doi.org/10.1038/280217a0
Sharp TG, Lingemann CM, Dupas C, Stöffler D (1997) Natural occurrence of MgSiO3-ilmenite and evidence for MgSiO3-perovskite in a shocked L chondrite. Science 277(5324):352–355. https://doi.org/10.1126/science.277.5324.352
Smith JV, Mason B (1970) Pyroxene-garnet transformation in Coorara meteorite. Science 168:832–833
Stöffler D, Ostertag R, Jammes C, Pfannschmidt G, Sen Gupta PR, Simon SB, Papike JJ, Beauchamp RH (1986) Shock metamorphism and petrography of the shergotty achondrite. Geochim Cosmochim Acta 50(6):889–903. https://doi.org/10.1016/0016-7037(86)90371-6
Tomioka N, Fujino K (1999) Akimotoite, (Mg,Fe)SiO3, a new silicate mineral of the ilmenite group in the Tenham chondrite. Am Mineral 84(3):267–271. https://doi.org/10.2138/am-1999-0307
Tomioka N, Miyahara M (2017) High-pressure minerals in shocked meteorites. Meteorit Planet Sci 52(9):2017–2039. https://doi.org/10.1111/maps.12902
Tomioka N, Bindi LC, Okuchi T, Miyahara M, Iitaka T, Li Z, Kawatsu T, Xie XD, Purevjav N, Tani R, Kodama Y (2021) Poirierite, a dense metastable polymorph of magnesium iron silicate in shocked meteorites. Commun Earth Environ 2:16. https://doi.org/10.1038/s43247-020-00090-7
Tschauner O, Ma C, Beckett JR, Prescher C, Prakapenka VB, Rossman GR (2014) Discovery of bridgmanite, the most abundant mineral in earth, in a shocked meteorite. Science 346(6213):1100–1102. https://doi.org/10.1126/science.1259369
Tschauner O, Ma C, Lanzirotti A, Newville MG (2020) Riesite, a new high pressure polymorph of TiO2 from the Ries impact structure. Minerals 10(1):78. https://doi.org/10.3390/min10010078
Tschauner O, Huang SC, Yang SY, Humayun M, Liu WJ, Gilbert Corder SN, Bechtel HA, Tischler J, Rossman GR (2021) Discovery of davemaoite, CaSiO3-perovskite, as a mineral from the lower mantle. Science 374(6569):891–894. https://doi.org/10.1126/science.abl8568
Tschermak G (1872) Die meteoriten von Schergotty und Gopalpur. Sitzber Akad Wiss Wien Math Naturwiss Kl Abt I 65:122–146
Xie XD (1973) Brief introduction of shock metamorphism. Geol Geochim 1:1–4
Xie XD, Chen M (2016) Suizhou meteorite: mineralogy and shock metamorphism. Springer, Berlin Heidelberg. https://doi.org/10.1007/978-3-662-48479-1
Xie XD, Gu XP (2023) The breakdown of diopside to (Ca, Mg)SiO3 perovskite–(Mg, Ca, Fe)SiO3 glass–(Mg, Ca)SiO3 glass–(Mg, Ca) SiO3 majorite in a melt vein the Suizhou L6 chondrite. Acta Geochim 42(2):183–194. https://doi.org/10.1007/s11631-023-00594-x
Xie XD, Liu JS, Xie HS (1990) Micromineralogical investigations on the metasomatism in mantle xenoliths from basalts in Southeastern China. Chin J Geochem 9(2):93–98. https://doi.org/10.1007/BF02838058
Xie XD, Chen M, El Goresy A, Gillet P (2000) Two high-pressure mineral assemblages in shock melt veins of the Suizhou L6 chondrite. Antarctic meteorites, XXV. NIPR, Tokyo, pp 181–183
Xie XD, Chen M, Wang DQ (2001a) Shock-related mineralogical features and P-T history of the Suizhou L6 chondrite. Eur J Mineral 13(6):1177–1190. https://doi.org/10.1127/0935-1221/2001/0013-1177
Xie XD, Chen M, Wang DQ, El Goresy A (2001b) NaAlSi3O8-hollandite and other high-pressure minerals in the shock melt veins of the Suizhou L6 meteorite. Chin Sci Bull 46(13):1116–1125. https://doi.org/10.1007/BF02900692
Xie XD, Minitti ME, Chen M, Mao HO, Wang DQ, Shu JF, Fei YW (2002a) Natural high-pressure polymorph of merrillite in the shock veins of the Suizhou meteorite. Geochim Cosmochim Acta 66(13):2439–2444. https://doi.org/10.1016/S0016-7037(02)00833-5
Xie ZD, Tomioka N, Sharp TG (2002b) Natural occurrence of Fe2SiO4-spinel in the shocked umbarger L6 chondrite. Am Mineral 87(8–9):1257–1260. https://doi.org/10.2138/am-2002-8-926
Xie XD, Minitti ME, Chen M, Wang DQ, Mao HK, Shu JF, Fei YW (2003) Tuite, γ-Ca3(PO4)2, a new phosphate mineral from the Suizhou L6 chondrite. Eur J Mineral 15:1001–1005
Xie XD, Sun ZY, Chen M (2011a) The distinct morphological and petrological features of shock melt veins in the Suizhou L6 chondrite. Meteorit Planet Sci 46(3):459–469. https://doi.org/10.1111/j.1945-5100.2011.01168.x
Xie XD, Chen M, Wang CY (2011b) Occurrence and mineral chemistry of chromite and xieite in the Suizhou L6 chondrite. Sci China Earth Sci 54(7):998–1010
Xie XD, Zhai SM, Chen M, Yang HX (2013) Tuite, γ-Ca3(PO4)2, formed by chlorapatite decomposition in a shock vein of the Suizhou L6 chondrite. Meteorit Planet Sci 48(8):1515–1523. https://doi.org/10.1111/maps.12143
Xie XD, Gu X, Chen M (2016a) An occurrence of tuite, γ-Ca3(PO4)2, partly transformed from Ca-phosphates in the Suizhou meteorite. Meteorit Planet Sci 51:195–202
Xie XD, Wang JB, Gu XP, Xiong Y, Jia SF (2016b) Transmission electron microscopic study of the fine-grained vein matrix in the Suizhou L6 meteorite. Acta Geochim 35(2):105–110. https://doi.org/10.1007/s11631-016-0093-7
Xie XD, Gu XP, Yang HX, Chen M, Li K (2020) Wangdaodeite, the LiNbO3-structured high-pressure polymorph of ilmenite, a new mineral from the Suizhou L6 chondrite. Meteorit Planet Sci 55(1):184–192. https://doi.org/10.1111/maps.13426
Xie XD, Gu XP, Chen M (2023) The discovery of TiO2-II, the α-PbO2-structured high-pressure polymorph of rutile, in the Suizhou L6 chondrite. Acta Geochim 42(1):1–8. https://doi.org/10.1007/s11631-022-00585-4
