Taxonomic notes on Anthomedusae (Cnidaria: Hydrozoa: Hydroidomedusa) from the south-central South China Sea, with a new genus and four new species
收藏切换
PDF
Feiyan DU1, 2, Lianggen WANG1, 2, Zhenzu XU3, Jiaqi HUANG3, Donghui GUO3, *
Acta Oceanologica Sinica | 2018, 37(10) : 112 - 118
Less
收藏切换
Acta Oceanologica Sinica | 2018, 37(10): 112-118
• Articles •
Taxonomic notes on Anthomedusae (Cnidaria: Hydrozoa: Hydroidomedusa) from the south-central South China Sea, with a new genus and four new species
Full
Feiyan DU1, 2, Lianggen WANG1, 2, Zhenzu XU3, Jiaqi HUANG3, Donghui GUO3, *
Affiliations
  • 1 South China Sea Fisheries Institute, Chinese Academy of Fishery Science, Guangzhou 510300, China
  • 2 Guangdong Province Key Laboratory of Fishery Ecology and Environment, Guangzhou 510300, China
  • 3 College of Ocean and Earth Sciences, Xiamen University, Xiamen 361102, China
Published: 2018-10-25 doi: 10.1007/s13131-018-1310-5
Outline
收藏切换

This study describes and illustrates four new species Laticanna nanhaiensis Xu, Huang and Wang, gen. nov. and sp. nov., Protiaropsis gemmifera Xu, Huang and Du, sp. nov., Merga nanhaiensis Xu, Huang and Guo, sp. nov. and Rhabdoon apiciloculus Xu, Huang and Du, sp. nov. based on specimens from the south-central South China Sea. Additionally, keys to known genera of family Bythotiaridae and species of genera Protiaropsis, Merga, and Rhabdoon are described. All type specimens are deposited in the South China Sea Fisheries Research Institute, Chinese Academy of Fishery Science.

Hydroidomedusae  /  Bythotiaridae  /  Pandeidae  /  Tubulariidae  /  new genus and species  /  South China Sea
Feiyan DU, Lianggen WANG, Zhenzu XU, Jiaqi HUANG, Donghui GUO. Taxonomic notes on Anthomedusae (Cnidaria: Hydrozoa: Hydroidomedusa) from the south-central South China Sea, with a new genus and four new species[J]. Acta Oceanologica Sinica, 2018 , 37 (10) : 112 -118 . DOI: 10.1007/s13131-018-1310-5
Full Text
Less
1 Introduction
Less
This is the second publication in a series of taxonomic revisions of Anthomedusae from the south-central South China Sea, which began with the family Ptilocodiidae (Wang et al., 2017).
This study treats the families Bythotiaridae, Pandeidae and Tubulariidae. Based on collections of the authors, one new genus and four new species under the subclass Anthomedusae were identified from the south-central South China Sea.
2 Materials and methods
Less
Specimens of the new species were collected from the region (9°05′–11°26′N, 113°54′–114°36′E) in the south-central South China Sea during May 2014. All planktonic samples were collected using a large-type zooplankton net (80 cm diameter, 0.505 mm mesh size) by vertical hauls from depth 200 m to surface. Specimens were fixed in 5% formalin buffered in seawater. Specimens were examined using stereoscopy and light microscopy, and taxonomic identification were undertaken based on the literatures specified in the references section.
3 Taxonomy
Less
List and taxonomic position of new genus and species
Class Hydroidomedusa Claus, 1877
Subclass Anthomedusae Haeckel, 1879
Order Filifera Kühn, 1913
Family Bythotiaridae Maas, 1905
Genus Laticanna Xu, Huang and Du, gen. nov.
Laticanna nanhaiensis Xu, Huang and Wang, sp. nov.
Genus Protiaropsis Stechow, 1919
Protiaropsis gemmifera Xu, Huang and Du, sp. nov.
Family Pandeidae Haeckel, 1879
Genus Merga Hartlaub, 1913
Merga nanhaiensis Xu, Huang and Guo, sp. nov.
Order Capitata Kühn, 1913
Family Tubulariidae Fleming, 1828
Genus Rhabdoon Keferstein and Ehlers, 1861
Rhabdoon apiciloculus Xu, Huang and Du, sp. nov.
Family Bythotiaridae Maas, 1905 (=Calycopsidae Hartlaub, 1913)
Laticanna Xu, Huang and Wang, gen. nov.
Type species: Laticanna nanhaiensis Xu, Huang and Wang, sp. nov.
Description. Bythotiaridae without apical projection, marginal bulbs absent; two kinds of tentacles, long, hollow tentacles with scattering cnidocysts and a small terminal knob, and short, solid ones without a terminal knob, basal portion of tentacles usually adnate to exumbrella; four unbranched radial canals very broad, without centripetal canal; without gastric peduncle, mouth simple, circular; gonads on manubrial wall, simple no transverse folds; no ocelli.
Etymology. The generic name Laticanna, meaning lati-canal, which refers to very broad radial canals.
Remarks. The new genus has the key characteristics of the family Bythotiaridae. The family is composed of the following genera: Bythocellata Nair, 1951; Bythotiara Günther, 1903; Calycopsis Fewkes, 1882; Eumedusa Bigelow, 1920; Gymnogonium Xu and Huang, 1994; Meator Bigelow, 1913; Protiaropsis Stechow, 1919; Pseudotiara Bouillon, 1980; Sibogita Maas, 1905 (Bouillon et al., 2006; Schuchert, 2010). Members of the new genus differ from the other genera of Bythotiaridae, because they have four very broad unbranched radial canals and two kinds of tentacles. Although Eumedusa also has two kinds of tentacles, Laticanna can be distinguished from Eumedusa by the following traits: (1) without centripetal canals; (2) gonads circular, surrounding all manubrium, no transverse folds; (3) mouth simple, circular; and (4) four long marginal tentacles.
Key to medusa genera of family Bythotiaridae
1. Centripetal canals, blind or joining base of manubrium….......…2
– No centripetal canals…....................................................…4
2. All tentacles hollow, cnidocysts only in the terminal knob..... ..........................................................…Calycopsis Fewkes, 1882
– Two kinds of tentacles…......................................................…3
3. 8–16 large, hollow tentacles, with rings of cnidocysts and ter minal knob; numerous small solid dwarf tentacles without terminal knob…............................…Eumedusa Bigelow, 1920
– 4 large perradial and numerous small tentacles, all without terminal knob.....................................…Meator Bigelow, 1913
4. Radial canals simple, unbranched….......................................…5
– Radial canals branched; gonad folded……..............................8
5. Radial canals very broad; 4 long, hollow tentacles with terminal knob; 4 short, solid tentacles without terminal knob….......... ...............................…Laticanna Xu, Huang and Du, gen. nov.
– Radial canals narrow; all tentacles hollow with terminal knob…6
6. Gonads smooth, adradial…...........…Pseudotiara Bouillon, 1980
– Gonads smooth, interradial…..........................................…7
7. 8 radial canals; marginal tentacles with abaxial basal ocelli...... ................................................................…Bythocellata Nair, 1951
– 4 radial canals; no ocelli.............…Protiaropsis Stechow, 1919
8. Radial canals branching repeatedly at various levels......… .............................................................…Sibogita Maas, 1905
– Radial canals simple or bifurcated….....................................…9
9. 4 radial canals simple or bifurcated; gonads interradial with transverse furrows; marginal bulbs absent…............................. ......................................................…Bythotiara Günther, 1903
– 2 simple and 2 bifurcated radial canals; gonads smooth per radial; marginal tentacles with basal swelling embedded in mesoglea...................……Gymnogonium Xu and Huang, 1994
Laticanna nanhaiensis Xu, Huang and Wang, gen. nov. and sp. nov. (Fig. 1)
Material examined. Holotype (SFI 003) collected from the southern South China Sea, Sta. S38 (7°30′N, 115°30′E), depth 2 927 m, sampling depth 200 to 0 m, 15 September 2013, collector Ning Jiajia.
Diagnosis. Umbrella bell-shaped with round dome, apex very thick, without apical projection; manubrium without gastric peduncle; four unbranched radial canals very broad, without centripetal canal; two kinds of tentacles, four long, hollow ones with a small terminal cnidocyst knob, and four short, solid ones without terminal knob; all tentacles without base swelling, but their basal part adnate to exumbrella, umbrellar margin without marginal lobe; no ocelli.
Description. Umbrella bell-shaped, 4.5 mm high, 3.5 mm wide, with round dome, apex very thick, but thinner toward the bell margin, without apical projection, exumbrella smooth without scattered cnidocyst; manubrium very voluminous, cylindrical without gastric peduncle, about half of the height of bell cavity; mouth simple, circular; four very broad unbranched radial canals and a narrow circular canal, with granular materials, no centripetal canal; gonads encircle the manubrium, extending from near its base almost to the mouth; two kinds of tentacles, four very extendible perradial hollow tentacles with scattering cnidocysts and a small terminal cnidocyst knob, four short, interradial solid tentacles without terminal knob, all tentacles without base swelling, but their basal part adnate to exumbrella; umbrellar margin without marginal lobe; no ocelli; velum narrow.
Distribution. The South China Sea.
Etymology. From the Latin nanhaiensis, meaning the South China Sea, which refers to where the species was first collected.
Protiaropsis gemmifera Xu, Huang and Du, sp. nov. (Fig. 2)
Material examined. Holotype (SFI 004) and paratype (SFI 005) collected from the southern South China Sea, Sta. B2ZI19 (14°24′N, 116°57′E), depth 4 100 m, sampling depth 240 m to 0 m, 4 August 2014, collector Wang Lianggen.
Diagnosis. Umbrella bell-shaped with round dome, apex very thick, without apical projection; manubrium without gastric peduncle, with several medusa-buds developing interradial region of the manubrium, no transverse folds; umbrella with 8 tentacles, no base swelling, each with a terminal cnidocyst cluster; umbrella margin with 8 marginal lobes; no ocelli and secondary tentacles.
Description. Umbrella bell-shaped, 4–6.5 mm high, 3–4 mm wide, with round dome, apex very thick, without apical projection; exumbrella smooth without scattered cnidocysts; manubrium pyramidal, no gastric peduncle, with a broad base, about 1/3 length of subumbrellar cavity; mouth simple, circular; with 4 radial canals and a circular canal; gonads with several medusa-buds developing interradial region of the manubrium, no transverse folds; 4 perradial and 4 interradial hollow primary marginal tentacles, without base swelling, but their basal part adnate to exumbrella, sunk into a narrow fissure between two marginal lobes; each tentacle with a terminal cnidocyst cluster, usually spherical and always arising abruptly from a very thin portion of the tentacle; no secondary tentacles; without ocelli; velum narrow.
Distribution. The southern South China Sea.
Etymology. From the Latin gemmifera, meaning gemmifer. The species name refers to the manubrium with medusa-buds.
Remarks. The new species has 4 simple radial canals; no centripetal canals; gonad interradial with no transverse folds; without secondary tentacles; no ocelli; with a marginal lobe between successive tentacles; tentacles without basal swelling. These features place this medusa in the genus Protiaropsis Stechow, 1919.
Only four valid species of Protiaropsis are known (Bouillon et al., 2006; Xu et al., 2016). This new species can be distinguished from other Protiaropsis species by its lack of gastric peduncle and presence 8 tentacles. However, similar to P. minor, each tentacle terminates with a large cnidocyst cluster. The major differences between them include: 8 tentacles and gonads with medusa buds developing interradial region of manubrium in P. gemmifera, and 16–24 tentacles, gonads with irregular transverse folds, and a lack of medusa buds in P. minor.
Key to the known species in genus Protiaropsis
1. Manubrium with gastric peduncle; with 4 large mass-like gon ads in interradial of manubrium…........................................ ............................…P. pedunculata Xu, Huang and Guo, 2016
– Manubrium without gastric peduncle................................……2
2. With 4 tentacles, with terminal knob of cnidocyst; with 4 perra dial exumbrella cnidocyst tracks clasping the bell margin, reaching 1/3 of exumbrella height; 4 pad-shaped gonads in interradial position on manubrium…............................... ............................…P. tetranema Xu, Huang and Wang, 2016
– With 8 or more tentacles….....................................................…3
3. With 8 tentacles, with medusa buds developing interradial reg ion of the manubrium…P. gemmifera Xu, Huang and Du, sp. nov.
– With more than 8 tentacles…..................................................…4
4. With 8–12 tentacles, each terminating more elongate, slight swel ling.......................................……P. anonyma (Maas, 1905)
– With 16–24 tentacles, each terminating in a large cnidocyst cluster….....................................…P. minor (Vanhöffen, 1911)
Family Pandeidae Haeckel, 1879
Genus Merga Hartlaub, 1914
Merga Hartlaub, 1914: 249; Kramp, 1961: 106; Bouillon et al., 2006: 193; Schuchert, 2007: 347–348; Xu et al., 2014: 318
Synonyms Tiarula Hartlaub, 1914 [type species: Tiarula tergestina Neppi and Stiasny, 1912]; Janiopsis Bouillon, 1980 [type species Janiopsis costata Bouillon, 1980]
Type species: Pandea violacea Agassiz and Mayer, 1899 by designation of Hartlaub, 1914
Diagnosis. Pandeid medusae with or without apical projection; exumbrella with or without longitudinal ridges and ribs; with mesenteries, stomach with cross-shaped base, manubrium not twisted, with simple or faintly folds oral lips; gonads smooth or granulate, covering interradial apical part of manubrium, at maturity extending adradially along mesenteries and radial canals; four, eight or more tentacles; with or without rudimentary bulbs or tentaculae, with or without ocelli.
Remarks. Hartlaub (1914) established the genus Merga to accommodate pandeid medusae that resemble Leuckartiara or Halitholus species but have gonads without folds. Merga is distinguished from Leuckartiara by gonads on interradial walls of manubrium, bipartite but with broad connection in upper half, with wide various degrees of folding, and from Halitholus by gonads adradial with or without horizontal interradial connection, gonad folds directed towards perradial.
Janiopsis Bouillon, 1980 is preoccupied by Janiopsis Rovereto, 1899 [Gastropoda: Buccinidae; fossils]. According to Schuchert (2010), Janiopsis Bouillon, 1980 is congeneric with Merga Hartlaub, 1914 and there is no need to introduce a replacement name. Janiopsis Bouillon is composed of six species, which are combinations, and include Merga costata (Bouillon, 1980) n. comb. (Schuchert, 2010); Merga apicirubellus (Xu et al., 2009) n. transl., Merga apicispottis (Xu et al., 2009) n. comb., Merga brevispura (Xu et al., 2009) n. comb., Merga nanshaensis (Xu et al., 2009) n. comb., and Merga unguliformis (Xu et al., 2009) n. comb. (Xu et al., 2014), if Janiopsis and Merga are considered synonyms. The diagnosis in Xu et al. (2014) suits the new scope of the genus Merga (as in the genus diagnosis).
Presently, a total of 16 medusae species (including one new species) of Merga is known (Bouillon et al., 2006; Xu et al., 2014), ten of which are reported from the South China Sea and Taiwan Strait.
Merga nanhaiensis Xu, Huang and Guo, sp. nov. (Fig. 3)
Material examined. Holotype (SFI 006) collected from the South China Sea, Sta. 15 (108°11′N, 21°17′E), depth 15.7 m, sampling depth 10 m to 0 m, 10 September 2014, collector Chen Haigang.
Diagnosis. Merga medusa without apical projection, exumbrella without longitudinal ridges and ribs; 8 tentacles and 8 rudimentary bulbs, no ocelli; without tentaculae; mouth margin not folded much; mesenteries long; gonads smooth.
Description. Umbrella of mature medusa rather spherical, jelly moderately thick, thickest at top; bell 3 mm high and 3 mm wide, without apical process; without manubrial peduncle; four moderately broad radial canals, smooth, radial canals attached to manubrium via mesenteries that run along about 1/2 of the manubrium height, circular canal smooth than radial canals; bell margin with eight large, elongated conical bulbs bearing eight tentacles without abaxial spurs, between pairs of tentacles with one rudimentary bulb, all tentacle bases and rudimentary bulbs without ocelli, tentacles very extensile, but often carried rolled up into a thick short spiral; manubrium large and long, almost reaching to velum level, cross-shaped in section, mouth margin with a few folds, four lips without folds; gonads very voluminous, in eight bulging adradial masses with an interradial connection at the top, with deep interradial fold, but gonad may also be covered in the interradial position, surface usually smooth, with up to 3–5 irregular folds (may also depend on state of contraction).
Distribution. The South China Sea.
Etymology. From the Latin nanhaiensis, meaning South China Sea. The species name refers to where the species was first collected.
Remarks. Based on species diagnosis, we attribute new species to the genus Merga Hartlaub, 1914. This new species is quite distinct from other Merga species, because it lacks an apical process, the exumbrella no longitudinal ridges and ribs, gonads are smooth, 8 tentacles, 8 rudimentary bulbs, and all tentacular bulbs without ocelli and abaxial spur. However, its large and broad mouth and with rudimentary bulbs is similar to Merga violacea (Agassiz and Mayer, 1899). This new species differs from the M. violacea by the following characteristics: (1) M. nanhaiensis has 8 marginal tentacles, between pairs of tentacles with 1 rudimentary bulb, but M. violacea with 8–16 tentacles, between pairs of tentacles with 2–3 rudimentary bulbs; (2) M. nanhaiensis has all tentacle bases and rudimentary bulbs without ocelli, but M. violacea all tentacle bases and rudimentary bulbs with a small ocellus; and (3) M. nanhaiensis has tentacle bases that are elongated conical-shaped, tentacles very extensile, but often carried rolled up into a thick short spiral, but M. violacea tentacle bases laterally flattened, thinning quite abruptly into round tentacles after some distance.
Key to medusae of all known species in genus Merga
1. Without apical process……........................................................2
– With a district apical process…..........................................…9
2. Gonad rough by warts and groove, red-brown manubrium, with tentaculae…..........................................M. reesi Russell, 1956
– Gonad smooth…...............................................................…3
3. Exumbrella with 20 longitudinal ridges and ribs; with 20 mar ginal tentacles; no abaxial ocelli…....................................... ............................M. nanshaensis (Xu, Huang and Lin, 2009)*
– Exumbrella without longitudinal ridges and ribs…..............…4
4. With 4 perradial tentacles…...................................................…5
– With 8–16 tentacles…......................................................…7
5. With 4 rudimentary bulbs, tentacular bulbs very large, ovali form base.…M. macrobulbosa Xu, Huang and Chen, 1991*
– Without rudimentary bulbs…..........................................…6
6. Without tentaculae; no ocelli…......…M. tregoubovii Picard, 1960
– With 20 tentaculae; with ocelli….......................................... .............................M. minutum (Xu, Huang and Chen, 1991)*
7. With small mouth and the triangular projections at the proxi mal end of the radial canals; 16 marginal tentacles, no rudi mentary bulbs…........................…M. treubeli Schuchert, 1996
– With large and broad mouth, without triangular projections at the proximal end of the radial canals; with rudimentary bulbs..........................................................................…8
8. 8–12 tentacles, 24–36 rudimentary bulbs; all with ocelli…...... ......................................…M. violacea (Agassiz and Mayer, 1899)
– 8 tentacles, 8 rudimentary bulbs; all without ocelli…....... ..........................M. nanhaiensis Xu, Huang and Guo, sp. nov.*
9. Perradial tentacular bulbs with abaxial spurs…..................…10
– Perradial tentacular bulbs without abaxial spurs…..............…12
10. Exumbrella with 4 longitudinal ridges and ribs; 4 tentacles and 4 rudimentary bulbs; mesenteries long….............................. .........................…M. brevispura (Xu, Huang and Guo, 2009)*
– Exumbrella without longitudinal ridges and ribs…..........…11
11. 4–8 tentacles, up to 8 rudimentary bulbs; mesenteries short. ...............................…M. tergestina (Neppi and Stiasny, 1912)*
– 8–16 tentacles, perradial bulbs with band-shaped ocelli; mesenteries long….....................…M. galleri Brinckmann, 1962
12. Exumbrella without longitudinal ridges and ribs, with 4 perra dial tentacles, tentacular bulbs elongated cylindrical, with 8 tentaculae; no ocelli...................…M. bulbosa Bouillon, 1980*
– Exumbrella with longitudinal ridges and ribs…..................…13
13. With 16 marginal tentacles; exumbrella with 32–48 interradial longitudinal ridges and ribs; with abaxial ocelli…............ .............................................…M. costata (Bouillon, 1980)
– With 4 marginal tentacles….........................................…14
14. Apical projection long conical, with a pigmented spot at tip; exumbrella with 12 longitudinal ridges and ribs; tentacular bulbs elongated conical.............................................................. ..............................M. apicispottis (Xu, Huang and Lin, 2009)*
– Apical projection short; exumbrella with 8 longitudinal ridges and ribs...........................................................…15
15. 4–8 rudimentary bulbs with a red ocellus at tip; gonads smooth not folded…M. apicirubellus (Xu, Huang and Guo, 2009)*
– 4 rudimentary bulbs without red ocelli at tip, but tentacular bulbs with abaxial ocelli; gonads ungulate-shaped…........ .....................…M. unguliformis (Xu, Huang and Lin, 2009)*
* Recorded in China seas.
Order Capitata Kühn, 1913
Family Tubulariidae Fleming, 1928
Genus Rhabdoon Keferstein and Ehlers, 1861
Rhabdoon Keferstein and Ehlers, 1861: 86; Bouillon, 1985: 112; Brinckmann-Voss, 1987: 135; Bouillon and Boero, 2000: 150; Bouillon et al., 2004: 108; Stepanjants and Kosobokova, 2006: 392; Bouillon et al., 2006: 253; Schuchert, 2010: 518; Xu et al., 2014: 428
Rhysomedusa Vannucci and Soares Moreira, 1966: 8; Brinckmann-Voss, 1970: 32
Pararhysomedusa Shirley and Leung, 1970: 5
Yokovia Margulis, 1989: 126
Eugotoea Margulis, 1989: 126; Bouillon et al., 2004: 92
Type species: Rhabdoon singulare Keferstein and Ehlers, 1861
Diagnosis. Medusa with a single hollow tentacle that ends in a sphere of radiating nematophores; exumbrella with meridional cnidocyst bands; vacuolated cells at apex of manubrium, along radial canals, and around the umbrella margin; four radial canals that correspond to four longitudinal mesogleal ribs on the exumbrellar surface; marginal bulbs absent or only one present where tentacle is attached; manubrium occupies most part of the subumbrella cavity or extends slightly beyond the umbrellar margin, gonads surrounded manubrium completely; cnidome includes stenoteles, desmonemes, and microbasic heteronemes.
Remarks. Until recently, Rhabdoon was assigned to suborder Tubulariida and family Tubulariidae (Bouillon, 1985; Margulis, 1989; Bouillon and Boero, 2000; Bouillon et al., 2006). Stepanjants and Kosobokova (2006) revised this genus. Because the polyp stage of Rhabdoon remains unknown, it is also not clear whether this genus belongs to the Tubulariidae or the Corymorphidae. Therefore, it was classified here as incerta sedi (Schuchert, 2010). We consider that this genus belongs to family Tubulariidae before an examination of the life cycles, which involve polyp and medusa stages.
Four species are included in this genus: Rhabdoon singulare Keferstein and Ehlers, 1861 (=Rhysomedusa pomponina Vannucci and Soares Moreira, 1966; Eugotoea petalina Margulis, 1989), Rhabdoon reesi (Shirley and Leung, 1970) (=Pararhysomedusa reesi Shirley and Leung, 1970; Yakovia polinae Margulis, 1989), Rhabdoon armata (Margulis, 1997) (= Eugotoea armata Margulia, 1989) and Rhabdoon apiciloculus sp. nov. (Fig. 4). R. singulare was collected in the Mediterranean Sea (Vannucci and Soares Moreira, 1966; Brinckmann-Voss, 1970; Goy, 1973, 1983; Benović and Lučić, 1996), south-eastern Atlantic (Pagès et al., 1992), Magellan Straits (Pagès and Orejas, 1999), off western Australia (Hamond, 1974), and the south-western Taiwan Strait of China (Xu et al., 2014); type locality: Messina, Italy. R. reesi was found at bathy- and meso-pelagic depths of the Arctic Ocean, including the Barents Sea (Stepanjants and Kosobokova, 2006); type locality: central Arctic Ocean. R. armata was found in the Southern Ocean, including the Orkeny Islands, the Weddell Sea and at the Cape Norvegia (Margulis, 1997). R. apiciloculus was collected in the South China Sea.
At present time, a total of 4 medusae species (including one new species) in Rhabdoon is known (Margulis, 1997; Bouillon et al., 2006; Schuchert, 2010; Xu et al., 2014), two of which are reported from the South China Sea and Taiwan Strait.
Rhabdoon apiciloculus Xu, Huang and Du, sp. nov. (Figs 4d, e)
Material examined. Holotype (SFI 007) collected from the South China Sea., Sta. B2Z15 (17°30′N, 116°56′E), depth 3 950 m, sampling depth 240 m to 0 m, 29 July 2014, collector Wang Lianggen.
Diagnosis. Umbrella near conical-shaped with rounded top; exumbrella with 16 longitudinal ribs of cnidocyst; manubrium with a large pointed apical chamber, entire manubrium and apical chamber covered vacuolated cells, and scattering along 4 radial canals; with a single hollow, long and thin tentacles that ends in a small knob of cnidocyst clusters; no marginal bulbs; without ocelli.
Description. Umbrella 2.5 mm high, 1.5 mm wide, near conical-shaped, with rounded top, lateral wall thick; exumbrella with 16 longitudinal ribs of cnidocyst, which includes 4 perradial, 4 interradial and 8 adradial cnidocyst ribs, all extend almost to the umbrella tip; manubrium very large and long, about as long as bell cavity, cylindrical, occupying almost entire bell cavity, without gastric peduncle, with a large pointed apical chamber; entire manubrium, apical chamber and bell margin covered vacuolated cells, and scattering along 4 radial canals; mouth simple, circular, covered with cnidocysts; 4 broad radial canals and 1 circular canal present; gonads surrounding distal 2/3 of manubrium; with a single hollow, long and thin marginal tentacle ending in a small knob of cnidocyst clusters; no marginal tentacular bulbs; ocelli absent; velum narrow.
Distribution. The South China Sea.
Etymology. From the Latin apiciloculus, meaning apical-locule. The species name refers to a large conical apical chamber at the apex of manubrium.
Remarks. This new species has a single hollow, smooth tentacle that ends with a cnidocyst knob; marginal bulbs totally absent; manubrium, apical chamber and umbrella margin covered with highly vacuolated cells, and scattering along broad radial canals; four thick perradial exumbrella cnidocyst ribs, plus four short interradial and eight adradial ones; ocelli absent. Based on these features characterized, we attribute our new species to the genus Rhabdoon Keferstein and Ehlers, 1861.
The major differences between R. reesi and R. singulare include the absence of marginal bulbs in R. singulare and the presence of a single well-developed bulb in R. reesi. Our new species is similar to R. singulare, because of the absence of marginal bulbs. However, the new species differs from R. singulare by the following characteristics: (1) R. apiciloculus has a manubrium with a large pointed apical chamber, whereas R. singulare lacks an apical chamber; (2) R. apiciloculus has a single hollow, long and thin tentacle that ends in a small knob of cnidocyst cluster, but R. singulare has a single hollow, short and thick tentacle that ends in a large knob consisting of numerous cnidocysts-containing stalked capitations; and (3) R. apiciloculus has umbrella near a conical-shaped, exumbrella with 16 longitudinal ribs of cnidocyst extend almost to the umbrella tip, but R. singulare has a nearly spherical bell, exumbrella with 4 long perradial cnidocyst ribs extend almost to the tip of the umbrella, other 4 interradial and 8 adradial shorter and slender cnidocyst ribs that extend only to the 1/3 high of bell.
Key to medusae of all known species in genus Rhabdoon
1. Marginal bulbs absent…................................................…2
– With one marginal bulb bearing the single tentacle…........ ................................................…R. reesi (Shirley and Leung, 1970)
2. Manubrium with a large pointed apical chamber…................. ..............................R. apiciloculus Xu, Huang and Du, sp. nov.
– Manubrium without apical chamber....................................……3
3. Exumbrella with 4 exerted, perradial longitudinal ribs, contain ing cnidocysts and an oblong brown spot in middle of each rib, 4 additional interradial and sometime adradial bands; manubrium with broad gastric peduncle…................................ ................................…R. singulare Keferstein and Ehlers, 1861
– Exumbrella with 4 not projected perradial facets without brown spots, only 8 adradial longitudinal ribs, containing cnidocysts; manubrium without gastric peduncle….................. ..............................................…R. armata (Margulis, 1997)
Funding
Less
  • The National Natural Science Foundation of China under contract No. 41406188; the Grant of China Ministry of Science and Technology under contract No. 2013BAD13B06; the Grant of Guangdong Province Ministry of Science and Technology under contract No. 2014A020217011; the Ministry of Agriculture Major Funding Projects under contract No. NFZX2013; the National Basic Research Program (973 Program) of China under contract No. 2011CB403604.
References
Less
Benović A, Lučić D. 1996. Comparision of hydromedusae findings in the northern and southern Adriatic Sea. Scientia Marina, 60(1): 129–135
Bouillon J. 1985. Essai de classification des Hydropolypes-Hydroméduses (Hydrozoa-Cnidaria). Indo-Malayan Zoology, 1: 29–243
Bouillon J, Boero F. 2000. Synopsis of the families and genera of the Hydromedusae of the world, with a list of the worldwide species. Thalassia Salentina, 24: 47–296
Bouillon J, Gravili C, Pagès F, et al. 2006. An introduction to Hydrozoa. Mémoires du Muséum national d’Histoire Naturelle, 194: 1–591
Bouillon J, Medel M D, Pagès F, et al. 2004. Fauna of the Mediterranean Hydrozoa. Scientia Marina, 68(S2): 5–438, doi: 10.3989/scimar.2004.68s2
Brinckmann-Voss A. 1970. Anthomedusae/athecata (Hydrozoa, Cnidaria) of the Mediterranean: Part I. Capitata. Fauna e Flora del Golfo di Napoli, 39: 1–96
Brinckmann-Voss A. 1987. Seasonal distribution of Hydromedusae (Cnidaria, Hydrozoa) from the Gulf of Naples and vicinity, with observations on sexual and asexual reproduction in some species. In: Bouillon J, Boero F, Cicogna F, et al, eds. Modern Trends in the Systematics, Ecology, and Evolution of Hydroids and Hydromedusae. Oxford: Clarendon Press, 133–141
Goy J. 1973. Les hydroméduses de la mer ligure. Bulletin du Muséum National d’Histoire Naturelle, Paris , 62: 965–1008
Goy J. 1983. Les hydromedusas dans les parages du detroit de gibraltar. Rapports et Proces Verbaux des Réunions Commission Internationale pour L’Exploration Scicentifigue de la Mer Mediterranée Monaco, 28: 133–134
Hamond R. 1974. Some medusae and other hydrozoa from the Indian Ocean and the Bass Strait. Journal of Natural History, 8(5): 549–561, doi: 10.1080/00222937400770471
Hartlaub C C. 1914. Craspedote medusen, teil 1, lieferung 3, Tiaridae. Nordisches Plankton, 6: 237–363
Keferstein W M, Ehler E H. 1861. Zoologische Beiträge Gesammelt im Winter 1859/60 in Neapel Und Messina (in German). Leipzig: W Engelmann, 1–112
Kramp P L. 1961. Synopsis of the medusae of the world. Journal of the Marine Biological Association of the United Kingdom, 40: 7–469, doi: 10.1017/S0025315400007347
Margulis R Y. 1989. Novye gidroidnye meduzy semestva Tubulariidae (Coelenterata, Hydrozoa). Zoologicheskii Zhurnal, 68(6): 126–130
Margulis R Y. 1997. A new hydromedusa (Cnidaria, Hydrozoa) from the southern ocean. Zoologicheskii Zhurnal, 76(1): 114–117
Pagès F, Gili J M, Bouillon J. 1992. Medusae (Hydrozoa, Scyphozoa, Cubozoa) of the Benguela Current (southeastern Atlantic). Scientia Marina, 56(S1): 1–64
Pagès F, Orejas, C. 1999. Medusae, siphonophores and ctenophores of the Magellan region. Scientia Marina, 63(S1): 51–57, doi: 10.3989/scimar.1999.63s1
Schuchert P. 2007. The European athecate hydroids and their medusae (Hydrozoa, Cnidaria): Filifera part 2. Revue Suisse de Zoologie, 114: 195–396, doi: 10.5962/bhl.part.80395
Schuchert P. 2010. The European athecate hydroids and their medusae (Hydrozoa, Cnidaria): Capitata part 2. Revue Suisse de Zoologie, 117(3): 337–555
Shirley W D, Leung Y M. 1970. Medusae of the central Arctic. In: Kobayashi H E, ed. Taxonomic Guides to Arctic Zooplankton II. Los Angeles: University of Southern California, 3–18
Stepanjants S D, Kosobokova K N. 2006. Medusae of the genus Rhabdoon (Hydrozoa: Anthomedusae: Tubularioidea) in the Arctic Ocean. Marine Biology Research, 2(6): 388–397, doi: 10.1080/17451000601012402
Vannucci M, Soares Moreira M G B. 1966. Some Hydromedusae from the Gulf of Naples with description of a new genus and species. Pubblicazioni della Stazione Zoologica di Napoli, 35: 7–12
Wang Lianggen, Du Feiyan, Xu Zhenzu, et al. 2017. Taxonomical notes on the family Ptilocodiidae (Anthomedusae) from the central and southern of South China Sea, with a new genus and a new species. Zoological Systematics, 42(2): 236–242
Xu Zhenzu, Huang Jiaqi, Lin Mao, et al. 2014. The Superclass Hydrozoa of the Phylum Cnidaria in China (in Chinese). Beijing: China Ocean Press, 318–325, 428–429
Xu Zhenzu, Huang Jiaqi, Lin Mao, et al. 2016. Taxonomic notes on Hydroidomedusae (Cnidaria) from South China Sea II: Family Bythotiaridae (Anthomedusae). Zoological Systematics, 41(2): 149–157
Appendix
Less
Year 2018 volume 37 Issue 10
PDF
38
20
Cite this Article
BibTeX
Article Info
doi: 10.1007/s13131-018-1310-5
  • Receive Date：2017-06-29
  • Online Date：2026-04-14
  • Published：2018-10-25
Article Data
Affiliations
History
  • Received：2017-06-29
  • Accepted：2017-11-23
Funding
The National Natural Science Foundation of China under contract No. 41406188; the Grant of China Ministry of Science and Technology under contract No. 2013BAD13B06; the Grant of Guangdong Province Ministry of Science and Technology under contract No. 2014A020217011; the Ministry of Agriculture Major Funding Projects under contract No. NFZX2013; the National Basic Research Program (973 Program) of China under contract No. 2011CB403604.
Affiliations
    1 South China Sea Fisheries Institute, Chinese Academy of Fishery Science, Guangzhou 510300, China
    2 Guangdong Province Key Laboratory of Fishery Ecology and Environment, Guangzhou 510300, China
    3 College of Ocean and Earth Sciences, Xiamen University, Xiamen 361102, China

Corresponding:

References
Share
https://castjournals.cast.org.cn/joweb/aos/EN/10.1007/s13131-018-1310-5
Share to
QR

Scan QR to access full text

Cite this article
BibTeX
Citations
表12种不同金属材料的力学参数
科
Family		 属数
Number of
genus		 种数
Number of
species		 占总种数比例
Percentage of
total species (%)		 属
Genus		 种数
Number of
species		 占总种数比例
Percentage of total
species (%)
鹅膏菌科Amanitaceae 2 11 5.26 鹅膏菌属 Amanita 10 4.78
小菇科 Mycenaceae 2 12 5.74 丝盖伞属 Inocybe 5 2.39
多孔菌科 Polyporaceae 8 14 6.70 蜡蘑属 Laccaria 5 2.39
红菇科 Russulaceae 3 23 11.00 小皮伞属 Marasmius 6 2.87
小菇属 Mycena 11 5.26
光柄菇属 Pluteus 5 2.39
红菇属 Russula 17 8.13
栓菌属 Trametes 5 2.39
关闭全屏
  • BibTeX
  • EndNote
  • RefWorks
  • TxT
Links
Articles
Latest Articles
Most Read
Collections
Updates
Events
News
Multimedia
About
About Us
Contact
No. 86 Xueyuan South Road, Haidian District, Beijing
100081
010-62199257
qkjq@cast.org.cn

Copyright © 2025 China Association for Science and Technology. All rights reserved. For all open access content, the relevant licensing terms apply.
Sponsored by the Office of the Leading Group for Cybersecurity and Informatization of CAST, and supported by Science and Technology Review Publishing House
