Detection of two pathogenic marine ciliates Ancistrum haliotis and A. crassum (Ciliophora: Scuticociliatia) by fluorescence in situ hybridization

Detection of two pathogenic marine ciliates Ancistrum haliotis and A. crassum (Ciliophora: Scuticociliatia) by fluorescence in situ hybridization

PDF

Zifeng Zhan¹^,²^,³, Kuidong Xu¹^,²^,³^,⁴^,^*

Acta Oceanologica Sinica | 2020, 39(12) : 90 - 94

Less

Acta Oceanologica Sinica | 2020, 39(12): 90-94

• Marine Biology •

Detection of two pathogenic marine ciliates Ancistrum haliotis and A. crassum (Ciliophora: Scuticociliatia) by fluorescence in situ hybridization

Full

Zifeng Zhan¹^,²^,³, Kuidong Xu¹^,²^,³^,⁴^,^*

Affiliations

¹ Laboratory of Marine Organism Taxonomy and Phylogeny, Institute of Oceanology, Chinese Academy of Sciences, Qingdao 266071, China

² Laboratory for Marine Biology and Biotechnology, Pilot National Laboratory for Marine Science and Technology (Qingdao), Qingdao 266237, China

³ Center for Ocean Mega-Science, Chinese Academy of Sciences, Qingdao 266071, China

⁴ University of Chinese Academy of Sciences, Beijing 100049, China

Published: 2020-12-25 doi: 10.1007/s13131-020-1683-0

Outline

Abstract

Less

The scuticociliatid ciliates Ancistrum haliotis and A. crassum are parasites that may cause high mortality in the cultured abalone Haliotis spp. and the bivalve Ruditapes philippinarum. Traditional identification with silver staining methods is hampered by their morphological similarities to closely related species and the complicated procedures of morphological analysis. We designed two SSU rRNA-targeted oligonucleotide probes labeled with a fluorochrome, and optimized the fluorescence in situ hybridization (FISH) protocols for identification of A. halioti and A. crassum, respectively. The assays resulted in a clear identification by strong fluorescence signals from the oligonucleotide probes. The method can be used for quick and accurate quantitative analysis of A. haliotis and A. crassum infections on host molluscs.

Key words

oligonucleotide probes / molecular methods / scuticociliates / SSU rRNA / abalone / mollusc

Cite this Article

Zifeng Zhan, Kuidong Xu. Detection of two pathogenic marine ciliates Ancistrum haliotis and A. crassum (Ciliophora: Scuticociliatia) by fluorescence in situ hybridization[J]. Acta Oceanologica Sinica, 2020 , 39 (12) : 90 -94 . DOI: 10.1007/s13131-020-1683-0

Full Text

Less

1 Introduction

Less

Ciliates assigned to the scuticociliate genus Ancistrum Maupas, 1883 are parasites of marine and freshwater molluscs (Chatton and Lwoff, 1949; Fenchel, 1965; Raabe, 1970; Xu and Song, 2003; Xu et al., 2015). Among these, Ancistrum haliotis Xu et al., 2015 is a pathogen that infects the gills and the mantle cavity of the abalone Haliotis spp., which is cultivated and has high economic importance in many countries (e.g., China, Japan, Australia). In case of mass occurrence, A. haliotis may cause high mortality in cultured abalones (especially juvenile) by weakening the respiratory function of the gill filaments and leading to secondary bacterial diseases. Ancistrum crassum Fenchel, 1965 is a parasite of the bivalves including Ruditapes philippinarum, Caecella chinensis, Protothaca jedoensis and Saxidomus purpuratus, which are also economical animals in China (Xu and Song, 2003). Like the case of A. haliotis, A. crassum can cause the mortality of R. philippinarum.

Morphological methods are the routine way to identify Ancistrum species, however, it has two significant limitations. First, Ancistrum spp. show morphologically high similarities to each other as well as other similar scuticociliates, which often concomitantly occur in the same host, e.g., Uronema marinum. The commonly used silver staining methods for morphological identification need considerable experience, and staining failure is often the case, making species identification difficult (Zhan et al., 2014, 2018). Second, these endoparasitic ciliates are hard to control when massive infection occurs in molluscs. Thus, early detection, quantification, and control (e.g., host animal isolation, changing the water, chemical treatment) of these infectious pathogens are crucial for mollusc aquaculture. There is a pressing need for a prompt and accurate diagnosis tool for these scuticociliates without the necessity of morphological identification.

FISH methods can circumvent the drawbacks of the morphological method (Stoeck et al., 2003; Zhan et al., 2014, 2018). FISH is based on the design of specific fluorochrome-labeled oligonucleotide probes that hybridize to a targeted sequence within an intact cell, resulting in colored signals that are detected with a fluorescence microscope (e.g., DeLong et al., 1989; Stoeck et al., 2003). FISH has been applied successfully to four pathogenic ciliates. Bourne et al. (2008) detected a scuticociliate associated with the coral disease brown band with two designed probes; and Zhan et al. (2014, 2018) designed three targeted probes to detect Pseudocohnilembus persalinus, Boveria labialis and B. subcylindrica, which infect the fish Paralichthys olivaceus, the sea cucumber Apostichopus japonicus and the bivalve Atrina pectinata, respectively.

Although sequencing-based methods are another molecular way to detect ciliated pathogens, it has one significant limitation in aquaculture practice. Usually, there are various microorganisms including nonparasitic scuticociliates in the gills and the mantle cavity of the hosts, and in the waters and sediments of aquaculture systems. Most scuticociliates are small-sized (usually 20–60 μm) and highly similar, and thus it is difficult to accurately isolate for sequencing. Alternatively, with the direct polymerase chain reaction (PCR) on the host tissues or the environmental samples, the target genes are often hard to be amplified when the cells are in low abundance. Furthermore, the sequencing-based methods can not obtain the number of the parasites. By contrast, FISH can visualize the target cells in any case (Stoeck et al., 2003; Zhan et al., 2014, 2018). Additionally, FISH is more convenient and much cheaper than the high-throughput sequencing.

In the present study, our aim is to develop a fast and user-friendly tool facilitating the identification and quantitative examination of A. haliotis and A. crassum. Here we designed two rRNA-targeted fluorochrome-labeled probes based on the small subunit rDNA (SSU rDNA) sequences, and tested the utility of these probes using FISH.

2 Materials and methods

Less

2.1 Collection, isolation and identification

The host abalone Haliotis discus hannai Ino and the bivalve R. philippinarum were collected from two temporary culture ponds in Qingdao, China. Specimens of A. haliotis and A. crassum were isolated from the gills and mantle cavity of the host. The fluid of the mantle cavity was first examined for ciliates, and then the gills were removed and washed with sterile filtered (0.45 µm pore size) seawater in a Petri dish. Ciliates were isolated with a micropipette and observed in vivo (Figs 1a and 2a) under a differential interference contrast microscope (Axio Imager Z2, Carl Zeiss GmbH). Protargol staining following Wilbert (1975) was used to reveal the ciliary and nuclear pattern for species identification (Figs 1b and 2b).

2.2 DNA extraction, PCR amplification, and sequencing

Ciliates were isolated using finely drawn glass pipettes, rinsed in filtered sterilized seawater, and transferred to 1.5 mL microcentrifuge tubes. DNA was extracted from 10 cells using the DNeasy tissue kit (Qiagen, Hildesheim, Germany). The amplification of SSU rDNA used the eukaryote universal EUK-A and EUK-B primers (Medlin et al., 1988). PCR cycling conditions, product purification and cloning followed Zhan et al. (2014). Sequencing was performed by Shanghai Sangon Biological Engineering and Technical Service Company (Shanghai, China) using an Applied Biosystems (ABI, Foster City, Canada) 3730 DNA Stretch Sequencer.

2.3 Design and test of the specific oligonucleotide probe

A set of probes (nucleotides, 18–22; GC contents, 50%–60%; nucleotide-nucleotide T_ms, 50–60°C) was designed using the probe design tool as implemented in the ARB software package for the SSU rDNA sequence of A. haliotis and A. crassum (Ludwig et al., 2004). Generated probes were checked against the GenBank sequence collection by a standard nucleotide-nucleotide BLAST search and were compared to an accessibility map of the SSU rRNA of Saccharomyces cerevisiae for hints of probe target sites with promising high signal intensities (Behrens et al., 2003). From the original probe candidates, probe Ah1030 (5′-GCTGATGGAGCTAATATGACCC-3′) for A. haliotis and probe Ac699 (5′-ACAAATTCCGTCCGTAATCG-3′) for A. crassum fulfilled the general criteria of potentially successful probes (Pernthaler et al., 2001). Other probes used included the universal Cy-3-labeled eukaryotic probe Euk1209R (5′-GGGCATCACAGACCTG-3′) (Giovannoni et al., 1988) and its Cy-3-labeled complement as a nonsense probe.

2.4 FISH staining

FISH was used to visualize A. haliotis and A. crassum both in field samples and mixed samples with both species as well as U. marinum that concomitantly occurred in the same host mollusc; the latter species served as a negative control. The basic hybridization followed the protocol of Stoeck et al. (2003) and Zhan et al. (2014). In short, cells were washed down from the gills and the mantle cavities with filtered seawater, and the sample water was fixed with Bouin’s solution and filtered onto 1.2 μm pore size white Isopore membrane filters (25 mm; Millipore GmbH, Schwalbach/Ts., Germany). The membranes were covered with hybridization buffer at 46°C for 2–3 h, which was followed by 15 min of washing with preheated washing buffer at 48°C. After this, the cells were washed with distilled water, counterstained with DAPI (4′, 6′-Diamidino-2-Phenylindole). The membranes were viewed and imaged under an epifluorescence microscope (Axio Imager Z2, Carl Zeiss GmbH) using the Rhod and DAPI filters. To allow direct signal comparison, microscope settings, such as excitation power, pinhole diameter, detection gain, amplifier offset, time exposure (55 ms for Cy3 signals, 48 ms for DAPI signals), and filter sets for fluorescence image acquisition were kept the same for all tests. Formamide concentrations ranged from 0% to 45% (the results with every 5% growth are shown in Figs 1i–r, 2i–r) for Ah1020- and Ac699-probe testing, and 30% for the universal eukaryote probe Euk1209R and the nonsense probe.

In order to assess the hybridization rates with the probes Ah1030 and Ac699, a total of 10, 20 and 30 cells of A. haliotis and A. crassum were added respectively to each 100 mL culture water, and were quantified with visualized red fluorescence signal count. The environmental water contained ciliates such as Euplotes spp. and Pseudokeronopsis sp., but no Ancistrum species were present. We also quantified the hybridization rate with probe Ah1030 from a mix of A. haliotis (30 cells) and a culture of U. marinum (10 mL).

3 Results and discussion

Less

The length, GC content (%), and GenBank accession number of the present SSU rRNA gene sequence of A. haliotis and A. crassum are as follows: 1 755 base pairs, 44%, HQ445963; 1 646 base pairs, 46%, MF407351. The new sequences were checked against the GenBank sequence collection by a standard nucleotide-nucleotide BLAST search, which were found to be at least 98% identity to the known Ancistrum sequences. The probes Ah1030 and Ac699 evaluated with the probe match tool of the ARB software package and the GenBank BLAST tool show that they are specific to A. haliotis and A. crassum, respectively. Probe Ah1030 has at least 3 mismatches to other species of Ancistrum as well as those like Cyclidium glaucoma. The GenBank BLAST shows that it has 14 mismatches to the host Haliotis discus hannai (Table 1). Probe Ac699 has 2 mismatches to other species of Ancistrum, and 3 mismatches to those like C. glaucoma (Table 1). The GenBank BLAST shows that it has at least 5 mismatches to the host R. philippinarum and 7 mismatches to H. discus hannai (Table 1).

Fluorescence in situ hybridization with the probes EUK1209R and Ah1030 resulted in the presence of an orange-red fluorescence signal in the cytoplasm for A. haliotis (Figs 1c, i–r), clear distinction from the faint autofluorescence signal achieved with negative-control hybridizations using the Ah1030 probe to hybridize the untargeted ciliates A. crassum and U. marinum (Figs 1e, g), and the nonsense probe (Fig. 1d). The FISH approach also provided some morphological information such as the shapes of the body, macronucleus and micronucleus (Figs 1c, d, h). This helped to verify morphotype identity in mixed taxa samples. The signal intensity of the probe Ah1030 became weaker when the formamide (FA) concentration increased in the hybridization buffers (Figs 1i–q), and the fluorescence signals with more than 25% FA (Figs 1o–r) were weaker than those of the positive control (Fig. 1c). Therefore, 25% of formamide in the hybridization was the optimal concentration for the stringency of probe Ah1030 (Fig. 1n). In the check of the rate of hybridization with probe Ah1030, all the cells of A. haliotis presented orange-red fluorescence signals by the FISH protocol with 25% FA concentration, which indicated the rate was 100%. The uniform time exposure with 48 ms was too long for U. marinum that their some bodies were artificially stained by the little remaining DAPI (e.g., Fig. 1h).

Fluorescence in situ hybridization with the probes EUK1209R and Ac699 resulted in the presence of an orange-red fluorescence signal in the cytoplasm for A. crassum (Figs 2c, i–r, t), clear distinction from the faint autofluorescence signal achieved with negative-control hybridizations using probe Ac699 to hybridize the untargeted ciliates A. haliotis and U. marinum (Figs 2e, g), and the nonsense probe (Fig. 2d). The signal intensity of probe Ac699 became weaker when the formamide (FA) concentration increased in the hybridization buffers (Figs 2i–r), and the fluorescence signals with more than 20% FA (Figs 2n–r) were weaker than those of the positive control (Fig. 2c). Therefore, 20% of formamide in the hybridization is the optimal concentration for the stringency of probe Ac699 (Fig. 2m). In the check of the rate hybridization with probe Ac699, only one cell in the trial with 30 targeted ciliates did not present the orange-red fluorescence signal by the FISH protocol with 20% FA concentration, which indicated the rate was at least 99.6%.

The present study developed the probes Ah1030 and Ac699 to unambiguously detect and identify A. haliotis from the abalone and A. crassum from the bivalve (Figs 1 and 2). Furthermore, due to the high hybridization rates (96.6%–100%) in our test cases, rapid quantification can be achieved in order to determine the intensity of A. haliotis and A. crassum infections. Our study demonstrates that the FISH method enables the rapid and accurate identification and enumeration of A. haliotis and A. crassum.

Funding

Less

The National Natural Science Foundation of China under contract Nos 41876171 and 41406171.

References

Less

Behrens S, Rühland C, Inácio J, et al. 2003. In situ accessibility of small-subunit rRNA of members of the domains Bacteria, Archaea, and Eucarya to Cy3-labeled oligonucleotide probes. Applied and Environmental Microbiology, 69(3): 1748–1758, doi: 10.1128/AEM.69.3.1748-1758.2003

Bourne D G, Boyett H V, Henderson M E, et al. 2008. Identification of a ciliate (Oligohymenophorea: Scuticociliatia) associated with brown band disease on corals of the Great Barrier Reef. Applied and Environmental Microbiology, 74(3): 883–888, doi: 10.1128/AEM.01124-07

Chatton E, Lwoff A. 1949. Recherches sur les ciliés thigmotriches. Archives de Zoologie Expérimentale et Générale, 86: 169–253

DeLong E F, Wickham G S, Pace N R. 1989. Phylogenetic stains: Ribosomal RNA-based probes for the identification of single cells. Science, 243(4896): 1360–1363, doi: 10.1126/science.2466341

Fenchel T. 1965. Ciliates from Scandinavian molluscs. Ophelia, 2(1): 71–174, doi: 10.1080/00785326.1965.10409598

Giovannoni S J, DeLong E F, Oslen G J, et al. 1988. Phylogenetic group-specific oligodeoxynucleotide probes for identification of single microbial cells. Journal of Bacteriology, 170(2): 720–726, doi: 10.1128/JB.170.2.720-726.1988

Ludwig W, Strunk O, Westram R, et al. 2004. ARB: a software environment for sequence data. Nucleic Acids Research, 32(4): 1363–1371, doi: 10.1093/nar/gkh293

Medlin L, Elwood H J, Stickel S, et al. 1988. The characterization of enzymatically amplified eukaryotic 16S-like rRNA-coding regions. Gene, 71(2): 491–499, doi: 10.1016/0378-1119(88)90066-2

Pernthaler J, Glöckner F P, Schöenhuber W, et al. 2001. Fluorescence in situ hybridization (FISH) with rRNA-targeted oligonucleotide probes. Methods in Microbiology, 30: 207–226, doi: 10.1016/S0580-9517(01)30046-6

Raabe Z. 1970. Ordo Thigmotricha (Ciliata–Holotricha): II. Familia Hemispeiridae. Acta Protozoologica, 7: 117–180

Stoeck T, Taylor G T, Epstein S S. 2003. Novel eukaryotes from the permanently anoxic Cariaco Basin (Caribbean Sea). Applied and Environmental Microbiology, 69(9): 5656–5663, doi: 10.1128/AEM.69.9.5656-5663.2003

Wilbert N. 1975. Eine verbesserte Technik der Protargolimprägnation für Ciliaten. Mikrokosmos, 64: 171–179

Xu Kuidong, Song Weibo. 2003. Parasitic ciliates of cultured molluscs. In: Song Weibo, Zhao Yuanjun, Xu Kuidong, et al., eds. Pathogenic Protozoa in Mariculture (in Chinese). Beijing: Science Press, 115–144

Xu Kuidong, Song Weibo, Warren A. 2015. Two new and two poorly known species of Ancistrum (Ciliophora, Scuticociliatia, Thigmotrichida) parasitizing marine molluscs from Chinese coastal waters of the Yellow Sea. Acta Protozoologica, 54(3): 195–208

Zhan Zifeng, Li Ju, Xu Kuidong. 2018. Detection and quantification of two parasitic ciliates Boveria labialis and Boveria subcylindrica (Ciliophora: Scuticociliatia) by fluorescence in situ hybridization. Journal of Eukaryotic Microbiology, 65(4): 440–447, doi: 10.1111/jeu.12488

Zhan Zifeng, Stoeck T, Dunthorn M, et al. 2014. Identification of the pathogenic ciliate Pseudocohnilembus persalinus (Oligohymenophorea: Scuticociliatia) by fluorescence in situ hybridization. European Journal of Protistology, 50(1): 16–24, doi: 10.1016/j.ejop.2013.09.004

Appendix

Less

Year 2020 volume 39 Issue 12

PDF

Cite this Article

BibTeX

Article Info

doi: 10.1007/s13131-020-1683-0

Receive Date：2020-02-14
Online Date：2026-03-31
Published：2020-12-25

Article Data

Affiliations

History

Received：2020-02-14
Accepted：2020-07-14

Funding

The National Natural Science Foundation of China under contract Nos 41876171 and 41406171.

Affiliations

¹ Laboratory of Marine Organism Taxonomy and Phylogeny, Institute of Oceanology, Chinese Academy of Sciences, Qingdao 266071, China

² Laboratory for Marine Biology and Biotechnology, Pilot National Laboratory for Marine Science and Technology (Qingdao), Qingdao 266237, China

³ Center for Ocean Mega-Science, Chinese Academy of Sciences, Qingdao 266071, China

⁴ University of Chinese Academy of Sciences, Beijing 100049, China

Corresponding:

* E-mail: kxu@qdio.ac.cn

References

Share

https://castjournals.cast.org.cn/joweb/aos/EN/10.1007/s13131-020-1683-0

Share to

Scan QR to access full text

Cite this article

BibTeX

Citations

表12种不同金属材料的力学参数

科 Family	属数 Number of genus	种数 Number of species	占总种数比例 Percentage of total species (%)	属 Genus	种数 Number of species	占总种数比例 Percentage of total species (%)
鹅膏菌科Amanitaceae	2	11	5.26	鹅膏菌属 Amanita	10	4.78
小菇科 Mycenaceae	2	12	5.74	丝盖伞属 Inocybe	5	2.39
多孔菌科 Polyporaceae	8	14	6.70	蜡蘑属 Laccaria	5	2.39
红菇科 Russulaceae	3	23	11.00	小皮伞属 Marasmius	6	2.87
				小菇属 Mycena	11	5.26
				光柄菇属 Pluteus	5	2.39
				红菇属 Russula	17	8.13
				栓菌属 Trametes	5	2.39

关闭全屏

BibTeX
EndNote
RefWorks
TxT

Table 1. Mismatches of the sequence alignments including the close related species and the hosts

Sequence accession number	Target alignment for probe Ac699	Target alignment for probe Ah1030
Sequence accession number	5′-UGUUUAAGGCAGGCAUUAGC-3′	5′-GGGUCAUAUUAGCUCCAUCAGC-3′
Note: Probe Ac699 (5′-ACAAATTCCGTCCGTAATCG-3′) is targeted for A. crassum, and probe Ah1030 (5′-GCTGATGGAGCTAATATGACCC-3′) is designed for A. haliotis. * represents same nucleotide to the target alignment, – gap in the alignment, and () insert in the alignment. Only nucleotides different to the target alignment (mismatches) are shown. New sequences are bold. The scuticociliates with more than 4 mismatches with target alignments are not shown.
Ancistrum crassum MF407351, HM236340, JQ956537, JQ956538	* * * * * * * * * * * * * * * * * * * *	* * * * CC * * * * * * T * * * * *
A. haliotis HQ445963	* * * * * * * * * * * * * GC * * *	* * * * * * * * * * * * * * * * * * * * * *
A. japonicum JQ956536	* * * * * * * * * * * * * GC * * *	* * * * CC * * * * * * T * * * * *
A. mytili JQ956535	* * * * * * * * * * * * * GC * * *	* * * * CC * * * * * * T C * * * *
Cyclidium glaucoma DQ442852, DQ442853, DQ442854	* * * * * * * * * * * * * GCA * *	* * * * CC * * * * * * T * * * * *
C. glaucoma HQ445963, KF256817, JQ956553	* * * * * * * * * * * * * GCA * *	* * * TCA * * * * * * T * * * * *
C. varibonneti KF256817	* * * * * * * * * * * * * GCA * *	* * * TCA * * * * * * T * * * * *
Uncultured Scuticociliatia clone JQ692043, JQ692041, EU446379	* * * * * * * * * * * * * GCA * *	* * * TCA * * * * * * T * * * * *
Ruditapes philippinarum AM774568, JN807342, EF426293	* C C * A * * * * C (GGC)C *	(A) (TT) CT * – G –* * GGCGG *
Ruditapes philippinarum JN807341	* C C * A * * * * C C *	A T GC T A T A * GGCGG *
Haliotis discus hannai KY485141, KY485142	* * * * * * A * * * * * (CAG)CCC *	(C)G(TT) C * * –* * * C A * * (GG) GGG * *–

Fig. 1. Ancistrum haliotis (a–d, i–r), A. crassum (e, f) and Uronema marinum (g, h), cells in vivo (a) and after protargol impregnation (b), simultaneous fluorescence in situ hybridization (FISH) and 4′, 6′-Diamidino-2-Phenylindole (DAPI) staining (c–r). For a–d, cells of A. haliotis in vivo (a), after protargol impregnation (b), hybridized with EUK1209R probe, with which only the Cy3-dye-derived light emission (orange red) is recorded (c), stained with the nonsense probe and DAPI, showing only the nucleus in blue (DAPI-derived light emission, d). For e–f, same cell of A. crassum stained with the Cy3-labled probe Ah1030 (e) and DAPI (f). For g–h, same cell of U. marinum stained with probe Ah1030 (g) and DAPI (h). For i–r, A. haliotis stained with the Cy3-labled probe Ah1030. The formamide concentration is 0%–45%, and the figures with every 5% increase in concentration are shown. Scale bar=15 μm.

Fig. 2. Ancistrum crassum (a–d, i–r), A. haliotis (e, f) and Uronema marinum (g, h), cells in vivo (a), after protargol impregnation (b), simultaneous fluorescence in situ hybridization (FISH) and 4′, 6′-Diamidino-2-Phenylindole (DAPI) staining (c–r). For a–d, cells of A. crassum in vivo (a), after protargol impregnation (b), hybridized with EUK1209R probe, with which only the Cy3-dye-derived light emission (orange red) is recorded (c), stained with the nonsense probe and DAPI, showing only the nucleus in blue (DAPI-derived light emission, d). For e–f, same cell of A. haliotis stained with the Cy3-labled probe Ac699 (e) and DAPI (f). For g–h, same cell of U. marinum stained with probe Ac699 (g) and DAPI (h). For i–r, A. haliotis stained with the Cy3-labled probe Ac699. The formamide concentration is 0%–45%, and the figures with every 5% increase in concentration are shown. The optimal formamide concentration is 20%. Scale bar=15 μm.
